Key No. Part No. Description Key No. Part No. Description

-147-

Electrical Parts List

KA8-XM15000 / KA8-XM150L00

KZ5-XM10000 / KZ5-XM100L00

C3620 303 409 3426 CERAMIC 0.1U K 16V

RESISTOR

R1885 301 226 1516 MT-GLAZE 0.000 ZA 1/16W

R1886 301 226 1516 MT-GLAZE 0.000 ZA 1/16W

R1887 301 226 1516 MT-GLAZE 0.000 ZA 1/16W

R1889 301 226 1516 MT-GLAZE 0.000 ZA 1/16W

R1890 301 226 1516 MT-GLAZE 0.000 ZA 1/16W

R1894 301 225 1210 MT-GLAZE 4.7K JA 1/16W

R1895 301 225 1210 MT-GLAZE 4.7K JA 1/16W

R1897 301 225 1210 MT-GLAZE 4.7K JA 1/16W

R1898 301 226 1516 MT-GLAZE 0.000 ZA 1/16W

R3610 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

R3611 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

R3612 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

R3613 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

R3614 301 162 2219 MT-GLAZE 10 JA 1/10W

R3615 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

R3616 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

R3617 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

R3618 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

R3619 301 150 5918 MT-GLAZE 10K JA 1/10W

R3620 301 150 5918 MT-GLAZE 10K JA 1/10W

R3621 301 256 4914 MT-GLAZE 360 JA 1/10W

R3623 301 037 5017 MT-GLAZE 0.000 ZA 1/10W

R3624 301 150 5918 MT-GLAZE 10K JA 1/10W

R3625 301 264 1813 MT-GLAZE 1K FA 1/10W

R3626 301 162 2714 MT-GLAZE 180 JA 1/10W

R3627 301 264 3718 MT-GLAZE 1.5K FA 1/10W

R3628 301 037 5017 MT-GLAZE 0.000 ZA 1/10W

R3629 301 150 5918 MT-GLAZE 10K JA 1/10W

R3630 301 150 5918 MT-GLAZE 10K JA 1/10W

R3631 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

R3632 301 162 2219 MT-GLAZE 10 JA 1/10W

R3633 301 162 2219 MT-GLAZE 10 JA 1/10W

R3634 301 190 1710 MT-GLAZE 0.000 ZA 1W

COIL

L3610 945 073 6408 IMPEDANCE,100 OHM -

L3612 945 073 6408 IMPEDANCE,100 OHM -

L3613 945 073 6408 IMPEDANCE,100 OHM -

L3625 945 002 5045 INDUCTOR,0.10U M

L3626 945 002 5045 INDUCTOR,0.10U M

L3627 945 002 5045 INDUCTOR,0.10U M

DIODE

D3601 307 163 0414 DIODE 1SS352-(TPH3)

307 149 0810 DIODE 1SS355-TE-17

D3602 307 163 0414 DIODE 1SS352-(TPH3)

307 149 0810 DIODE 1SS355-TE-17

D3603 307 223 5014 DIODE D1FM3

MISCELLANEOUS

K31B 645 098 7168 PLUG,D-SUB 25P

SC3611 945 076 3503 SURGE-ABSORBER

SC3612 945 076 3503 SURGE-ABSORBER

SC3613 945 076 3503 SURGE-ABSORBER

SC3614 945 076 3503 SURGE-ABSORBER

SC3615 945 076 3503 SURGE-ABSORBER

SC3616 945 076 3503 SURGE-ABSORBER

SC3617 945 076 3503 SURGE-ABSORBER

SC3618 945 076 3503 SURGE-ABSORBER

A6800 655 003 0955 ASSY,PWB,F/T RC+LED KA8AL

CAPACITOR

C2851 303 358 8319 CERAMIC 1U K 10V

C2852 303 157 6615 CERAMIC 470P K 50V

C2853 303 450 7012 CERAMIC 47U K 10V

C2854 303 358 8319 CERAMIC 1U K 10V

C2855 303 157 6615 CERAMIC 470P K 50V

C2856 303 450 7012 CERAMIC 47U K 10V

C6891 303 367 0410 CERAMIC 0.1U K 50V

RESISTOR

R2851 301 256 5614 MT-GLAZE 47 JA 1/10W

R2852 301 255 6513 MT-GLAZE 100 JA 1/10W

R2853 301 256 5614 MT-GLAZE 47 JA 1/10W

R2854 301 255 6513 MT-GLAZE 100 JA 1/10W

R6891 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

R6892 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

R6893 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

R6894 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

R6895 301 150 6014 MT-GLAZE 0.000 ZA 1/10W

R6896 301 255 5813 MT-GLAZE 2K JA 1/10W

DIODE

D6881 307 203 7915 LED SML-210MT T86 M

D6882 307 203 7816 LED SML-210LT T86 M

D6883 307 203 7816 LED SML-210LT T86 M

D6884 307 209 7513 LED SML-210YT T86 L

D6885 307 203 7717 LED SML-210DT T86 L

D6886 407 259 7515 LED SMLE12BC7TT86

D6892 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)

307 221 7119 ZENER DIODE UDZS-TE-1712B

408 063 1802 ZENER DIODE MM3Z12B

MISCELLANEOUS

AU2801 945 084 1997 UNIT,REMOCON RECEIVER

AU2801A 610 349 0656 HOLDER RC-KA8AL

AU2803 645 101 9004 UNIT,REMOCON RECEIVER

A6870 655 003 0948 ASSY, PWB ,CONTROL KA8AL

CAPACITOR

C6878 303 409 3426 CERAMIC 0.1U K 16V

RESISTOR

R6871 301 225 1814 MT-GLAZE 47 JA 1/16W

R6872 301 225 1814 MT-GLAZE 47 JA 1/16W

R6873 301 225 1814 MT-GLAZE 47 JA 1/16W

R6874 301 225 1814 MT-GLAZE 47 JA 1/16W

R6875 301 225 1814 MT-GLAZE 47 JA 1/16W

R6876 301 225 1814 MT-GLAZE 47 JA 1/16W

R6878 301 226 1516 MT-GLAZE 0.000 ZA 1/16W

DIODE

D6871 307 222 5916 ZENER DIODE UDZS3.6B-TE-17

408 063 4209 ZENER DIODE MM3Z3V6B

D6872 307 163 0414 DIODE 1SS352-(TPH3)

307 149 0810 DIODE 1SS355-TE-17

408 062 7201 DIODE 1SS35

D6873 307 222 5916 ZENER DIODE UDZS3.6B-TE-17

408 063 4209 ZENER DIODE MM3Z3V6B

D6874 307 163 0414 DIODE 1SS352-(TPH3)

307 149 0810 DIODE 1SS355-TE-17

408 062 7201 DIODE 1SS35

D6875 307 222 5916 ZENER DIODE UDZS3.6B-TE-17

408 063 4209 ZENER DIODE MM3Z3V6B

D6876 307 163 0414 DIODE 1SS352-(TPH3)

307 149 0810 DIODE 1SS355-TE-17

408 062 7201 DIODE 1SS35

D6877 307 222 5916 ZENER DIODE UDZS3.6B-TE-17

408 063 4209 ZENER DIODE MM3Z3V6B

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Analog signal format system	NTSC, PAL, SECAM
S-Video inputs quantity	1
Dimensions (WxDxH)	489.5 x 371.1 x 164 mm
Noise level	38 dB
Power consumption (standby)	0.6 W
Power consumption (typical)	400 W
Power consumption (economy mode)	338 W
