Sanyo PLC-XM100L Service Manual

Key No. Part No. Description Key No. Part No. Description
Electrical Parts List
-148-
KA8-XM15000 / KA8-XM150L00
KZ5-XM10000 / KZ5-XM100L00
D6878 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
408 063 4209 ZENER DIODE MM3Z3V6B
D6879 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
408 063 4209 ZENER DIODE MM3Z3V6B
D6880 307 222 5916 ZENER DIODE UDZS3.6B-TE-17
408 063 4209 ZENER DIODE MM3Z3V6B
D6895 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
307 221 7119 ZENER DIODE UDZS-TE-1712B
408 063 1802 ZENER DIODE MM3Z12B
MISCELLANEOUS
SW6871 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6872 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6873 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6874 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6875 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6876 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6877 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6878 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6879 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6880 945 026 2792 SWITCH,PUSH 1P-1TX1
AA600 655 003 0924 ASSY, PWB, POWER KA8AL
TRANSISTOR
Q601 405 218 6002 TR 2SK3934 LBS1
Q604 405 218 6002 TR 2SK3934 LBS1
Q612 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q613 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q621 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q622 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q651 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q652 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q681 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q682 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC601 309 523 1413 IC FA5502M
IC603 409 700 8703 IC STR-A6079
IC651 309 558 4202 IC STR-Z2156A
IC681 409 692 2515 IC TA76L431FB
CAPACITOR
! C601 304 088 8805 MT-POLYEST 0.22U M 275V
304 094 1807 MT-POLYEST 0.22U K 275V
! C602 304 088 8805 MT-POLYEST 0.22U M 275V
304 094 1807 MT-POLYEST 0.22U K 275V
! C603 304 073 5109 CERAMIC 470P K 250V
! C604 304 073 5109 CERAMIC 470P K 250V
! C605 304 088 8805 MT-POLYEST 0.22U M 275V
304 094 1807 MT-POLYEST 0.22U K 275V
! C606 304 073 4508 CERAMIC 2200P K 250V
! C607 303 371 8518 MT-POLYEST 1U K 400V
! C608 303 222 1326 CERAMIC 1000P K 1K
! C609 303 222 1326 CERAMIC 1000P K 1K
! C610 304 073 4508 CERAMIC 2200P K 250V
! C611 303 371 8518 MT-POLYEST 1U K 400V
C613 303 410 7113 ELECT 100U M 25V
C614 303 410 7113 ELECT 100U M 25V
C616 404 115 2704 ELECT 330U M 420V
404 115 6306 ELECT 330U M 420V
C618 303 427 1814 MT-POLYEST 0.1U K 450V
C619 303 298 9612 CERAMIC 0.1U K 16V
C621 303 205 2811 CERAMIC 0.047U K 25V
C622 303 157 6417 CERAMIC 330P K 50V
C623 303 215 2214 CERAMIC 0.01U K 50V
C624 303 342 3313 CERAMIC 0.1U K 25V
C625 303 394 5815 CERAMIC 4.7U K 16V
C627 303 342 3313 CERAMIC 0.1U K 25V
C628 303 157 3317 CERAMIC 68P J 50V
C629 303 157 6615 CERAMIC 470P K 50V
C630 303 342 3313 CERAMIC 0.1U K 25V
C631 303 298 9612 CERAMIC 0.1U K 16V
C632 303 342 3313 CERAMIC 0.1U K 25V
C633 303 342 3313 CERAMIC 0.1U K 25V
C635 303 409 9913 ELECT 470U M 16V
C636 303 427 1814 MT-POLYEST 0.1U K 450V
C637 403 477 6514 MT-POLYEST 0.01U J 630V
C640 304 097 3204 ELECT 22U M 50V
C641 303 215 2214 CERAMIC 0.01U K 50V
C642 404 122 5002 ELECT 15U M 450V
C650 303 342 3313 CERAMIC 0.1U K 25V
C651 303 268 7013 TA-SOLID 2.2U M 35V
C652 403 366 2917 CERAMIC 0.22U K 50V
C653 303 113 3818 CERAMIC 1000P K 50V
C654 303 247 3319 CERAMIC 330P K 2K
C656 303 342 3313 CERAMIC 0.1U K 25V
C657 303 218 8817 CERAMIC 220P K 2K
C658 303 083 4310 POLYPRO 0.022U J 400V

Sanyo PLC-XM100L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Analog signal format system	NTSC, PAL, SECAM
S-Video inputs quantity	1
Dimensions (WxDxH)	489.5 x 371.1 x 164 mm
Noise level	38 dB
Power consumption (standby)	0.6 W
Power consumption (typical)	400 W
Power consumption (economy mode)	338 W

Weight and Dimensions

Weight	8900 g
