-48-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
100 CLK_SHIFT_STATUS - -
101 REGISTER_STATUS - -
100 CXA7009R
0 G SIG Center 0 ~ 63 47
1 B SIG Center 0 ~ 63 47
2 R SIG Center 0 ~ 63 47
3 G Gain Control 0 ~ 255 224
4 B Gain Control 0 ~ 255 224
5 R Gain Control 0 ~ 255 224
6 G Bright Control 0 ~ 255 0
7 B Bright Control 0 ~ 255 0
8 R Bright Control 0 ~ 255 0
9 G VCOM Control 0 ~ 255 92 * Common voltage adj.
10 B VCOM Control 0 ~ 255 92 * Common voltage adj.
11 R VCOM Control 0 ~ 255 92 * Common voltage adj.
12 G SID Control A 0 ~ 255 7
13 B SID Control A 0 ~ 255 7
14 R SID Control A 0 ~ 255 7
15 G SID Control B 0 ~ 255 149
16 B SID Control B 0 ~ 255 149
17 R SID Control B 0 ~ 255 149
18 G FRINV 0 ~ 1 1
19 B FRINV 0 ~ 1 0
20 R FRINV 0 ~ 1 0
101 CXD3540_TG
0 SCANM 0 ~ 3 2
1 FRPM 0 ~ 2 2 * Common voltage adj.
2 SCAN_SEL 0 ~1 1
3 HP 0 ~ 2047 18
4 VP_G 0 ~ 255 6
5 SHP_R 0 ~ 127 26
6 SHP_G 0 ~ 127 26
7 SHP_B 0 ~ 127 26
8 FRP_HP 0 ~ 2047 58
9 PRG_U 0 ~ 1023 58
10 PRG_D 0 ~ 1023 100
11 HST_R_PF 0 ~ 127 12
12 HST_R_PC 0 ~ 127 7
13 DCK1_R_WA 0 ~ 127 5
14 DCK1_R_F 0 ~ 127 24
15 DCK2_R_WA 0 ~ 127 6
16 DCK2_R_F 0 ~ 127 24
17 DCK3_R_WA 0 ~ 127 5
18 DCK3_R_F 0 ~ 127 0
19 DCK4_R_WA 0 ~ 127 0
20 DCK4_R_F 0 ~ 127 0
21 HST_G_PF 0 ~ 127 12
22 HST_G_PC 0 ~ 127 9
23 DCK1_G_WA 0 ~ 127 5
24 DCK1_G_F 0 ~ 127 0
25 DCK2_G_WA 0 ~ 127 0
26 DCK2_G_F 0 ~ 127 0
27 DCK3_G_WA 0 ~ 127 5
28 DCK3_G_F 0 ~ 127 24
29 DCK4_G_WA 0 ~ 127 0
30 DCK4_G_F 0 ~ 127 0
31 HST_B_PF 0 ~ 127 12
32 HST_B_PC 0 ~ 127 9
33 DCK1_B_WA 0 ~ 127 5
34 DCK1_B_F 0 ~ 127 24
35 DCK2_B_WA 0 ~ 127 0
36 DCK2_B_F 0 ~ 127 0
37 DCK3_B_WA 0 ~ 127 5
38 DCK3_B_F 0 ~ 127 0
39 DCK4_B_WA 0 ~ 127 0
40 DCK4_B_F 0 ~ 127 0
41 PCG_U 0 ~ 1023 58
42 PCG_D 0 ~ 1023 144
To Next Page
