-49-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
43 ENB_U 0 ~ 1023 103
44 ENB_D 0 ~ 1023 44
45 CLR_U 0 ~ 1023 86
46 CLR_D 0 ~ 1023 30
47 VCKP 0 ~ 2047 58
48 VCKPD 0 ~ 2047 1344
49 VSTP 0 ~ 255 78
50 DFT_ON 0 ~ 1 0
51 HPC_R_DAT0 0 ~ 8191 0
52 HPC_R_DAT1 0 ~ 8191 0
53 HPC_G_DAT0 0 ~ 8191 0
54 HPC_G_DAT1 0 ~ 8191 0
55 HPC_B_DAT0 0 ~ 8191 0
56 HPC_B_DAT1 0 ~ 8191 0
57 SCAN_HP 0 ~ 2047 58
102 CXD3540_DSD_PRE
0 USR_R_GAIN 0 ~ 1023 512
1 USR_G_GAIN 0 ~ 1023 512
2 USR_B_GAIN 0 ~ 1023 512
3 USR_R_BRIGHT 0 ~ 8191 0
4 USR_G_BRIGHT 0 ~ 8191 0
5 USR_B_BRIGHT 0 ~ 8191 0
6 FRM_DAT 0 ~ 255 0
7 SEL_MODE 0 ~ 7 5
8 RLR_DUM_PIX 0 ~ 127 4
103 CXD3540_GAM
0 GAM_ON 0 ~ 1 1
1 GAM_R_GAIN 0 ~ 1023 512
2 GAM_G_GAIN 0 ~ 1023 512
3 GAM_B_GAIN 0 ~ 1023 512
4 GAM_R_BRIGHT 0 ~ 8191 0 * White balance adj
5 GAM_G_BRIGHT 0 ~ 8191 0
6 GAM_B_BRIGHT 0 ~ 8191 0 * White balance adj.
104 CXD3540_VXT
0 VXT_DETECT_ON 0 ~ 1 1
1 VXT_GSEL 0 ~ 3 2
2 VXT_RCALC 0 ~ 1 0
3 VXT_GCALC 0 ~ 1 0
4 VXT_BCALC 0 ~ 1 0
5 VXT_ON 0 ~ 1 1
6 VXT_RDATU1 0 ~ 255 8
7 VXT_RDATU2 0 ~ 255 7
8 VXT_RDATU3 0 ~ 255 1
9 VXT_GDATU1 0 ~ 255 8
10 VXT_GDATU2 0 ~ 255 7
11 VXT_GDATU3 0 ~ 255 1
12 VXT_BDATU1 0 ~ 255 8
13 VXT_BDATU2 0 ~ 255 7
14 VXT_BDATU3 0 ~ 255 1
15 VXT_RDATL1 0 ~ 255 4
16 VXT_RDATL2 0 ~ 255 3
17 VXT_RDATL3 0 ~ 255 1
18 VXT_GDATL1 0 ~ 255 4
19 VXT_GDATL2 0 ~ 255 3
20 VXT_GDATL3 0 ~ 255 1
21 VXT_BDATL1 0 ~ 255 4
22 VXT_BDATL2 0 ~ 255 3
23 VXT_BDATL3 0 ~ 255 1
24 VXT_TH_ON 0 ~ 15 15
25 VXT_TH1 0 ~ 255 38
26 VXT_TH2 0 ~ 255 81
27 VXT_TH3 0 ~ 255 226
28 VXT_TH4 0 ~ 255 240
105 CXD3540_CSC
0 CSC_XH 0 ~ 1 0
1 CSC_ON 0 ~ 1 1
To Next Page
