Sanyo PLC-XM100L Service Manual

-50-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
2 CSC_R_GP1 0 ~ 511 318
3 CSC_R_GP2 0 ~ 511 290
4 CSC_R_GP3 0 ~ 511 243
5 CSC_R_GP4 0 ~ 511 184
6 CSC_R_GP5 0 ~ 511 0
7 CSC_R_GP6 0 ~ 511 0
8 CSC_R_GP7 0 ~ 511 0
9 CSC_R_GP8 0 ~ 511 0
10 CSC_G_GP1 0 ~ 511 324
11 CSC_G_GP2 0 ~ 511 296
12 CSC_G_GP3 0 ~ 511 255
13 CSC_G_GP4 0 ~ 511 206
14 CSC_G_GP5 0 ~ 511 0
15 CSC_G_GP6 0 ~ 511 0
16 CSC_G_GP7 0 ~ 511 0
17 CSC_G_GP8 0 ~ 511 0
18 CSC_B_GP1 0 ~ 511 328
19 CSC_B_GP2 0 ~ 511 299
20 CSC_B_GP3 0 ~ 511 258
21 CSC_B_GP4 0 ~ 511 213
22 CSC_B_GP5 0 ~ 511 0
23 CSC_B_GP6 0 ~ 511 0
24 CSC_B_GP7 0 ~ 511 0
25 CSC_B_GP8 0 ~ 511 0
106 CXD3540_SHAD
0 SHAD_GSEL 0 ~ 3 2
1 SHAD_R_CALC 0 ~ 1 1
2 SHAD_G_CALC 0 ~ 1 1
3 SHAD_B_CALC 0 ~ 1 1
4 SHAD_ON 0 ~ 1 1
5 SHAD_R_DAT1 0 ~ 255 44
6 SHAD_R_DAT2 0 ~ 255 13
7 SHAD_R_DAT3 0 ~ 255 0
8 SHAD_G_DAT1 0 ~ 255 44
9 SHAD_G_DAT2 0 ~ 255 13
10 SHAD_G_DAT3 0 ~ 255 0
11 SHAD_B_DAT1 0 ~ 255 44
12 SHAD_B_DAT2 0 ~ 255 13
13 SHAD_B_DAT3 0 ~ 255 0
14 SHAD_COEF 0 ~ 4095 1365
107 CXD3540_VS
0 VS_GSEL 0 ~ 3 0
1 VS_R_RGT 0 ~ 1 0
2 VS_G_RGT 0 ~ 1 0
3 VS_B_RGT 0 ~ 1 0
4 VS_CYCLE 0 ~ 1 0
5 VS_ON 0 ~ 1 0
6 VS_GDAT1 0 ~ 255 0
7 VS_DAT 0 ~ 255 0
8 VS_GDAT3 0 ~ 255 0
9 VS_GDAT2 0 ~ 255 0
108 CXD3540_DSDPOST1
0 HXT_TH4_ON 0 ~ 1 0
1 HXT_TH3_ON 0 ~ 1 0
2 HXT_TH2_ON 0 ~ 1 0
3 HXT_TH1_ON 0 ~ 1 0
4 HXT_ON 0 ~ 1 0
5 HXT_RCALC 0 ~ 1 0
6 HXT_GCALC 0 ~ 1 0
7 HXT_BCALC 0 ~ 1 0
8 HXT_GSEL 0 ~ 1 0
9 HXT_RDAT1 0 ~ 255 0
10 HXT_RDAT2 0 ~ 255 0
11 HXT_RDAT3 0 ~ 255 0
12 HXT_GDAT1 0 ~ 255 0
13 HXT_GDAT2 0 ~ 255 0
14 HXT_GDAT3 0 ~ 255 0

Sanyo PLC-XM100L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Analog signal format system	NTSC, PAL, SECAM
S-Video inputs quantity	1
Dimensions (WxDxH)	489.5 x 371.1 x 164 mm
Noise level	38 dB
Power consumption (standby)	0.6 W
Power consumption (typical)	400 W
Power consumption (economy mode)	338 W

Weight and Dimensions

Weight	8900 g
