-54-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
2 Filter 1st Cartridge Scroll Factor 3
1st Filter Cartridge Scrolling Factor at N times Scrolling (N:1-10)
0: Manual Scrolling with OSD Menu
1: Auto Scrolling detecting by Filter Clogged
2: Auto Scrolling detecting by specified maximum used time per
a sheet
0 - 255 255
3 Filter 1st Cartridge Scroll Factor 4 0 - 255 255
4 Filter 1st Cartridge Scroll Factor 5 0 - 255 255
5 Filter 1st Cartridge Scroll Factor 6 0 - 255 255
6 Filter 1st Cartridge Scroll Factor 7 0 - 255 255
7 Filter 1st Cartridge Scroll Factor 8 0 - 255 255
8 Filter 1st Cartridge Scroll Factor 9 0 - 255 255
9 Filter 1st Cartridge Scroll Factor 10 0 - 255 255
10 Filter 2nd Cartridge Scroll Factor 1
2nd Filter Cartridge Scrolling Factor at N times Scrolling (N:1-10)
0: Manual Scrolling with OSD Menu
1: Auto Scrolling detecting by Filter Clogged
2: Auto Scrolling detecting by specified maximum used time per
a sheet
0 - 255 255
11 Filter 2nd Cartridge Scroll Factor 2 0 - 255 255
12 Filter 2nd Cartridge Scroll Factor 3 0 - 255 255
13 Filter 2nd Cartridge Scroll Factor 4 0 - 255 255
14 Filter 2nd Cartridge Scroll Factor 5 0 - 255 255
15 Filter 2nd Cartridge Scroll Factor 6 0 - 255 255
16 Filter 2nd Cartridge Scroll Factor 7 0 - 255 255
17 Filter 2nd Cartridge Scroll Factor 8 0 - 255 255
18 Filter 2nd Cartridge Scroll Factor 9 0 - 255 255
19
Filter 2nd Cartridge Scroll Factor
10
0 - 255 255
20 Filter 3rd Cartridge Scroll Factor 1
3rd Filter Cartridge Scrolling Factor at N times Scrolling (N:1-10)
0: Manual Scrolling with OSD Menu
1: Auto Scrolling detecting by Filter Clogged
2: Auto Scrolling detecting by specified maximum used time per
a sheet
0 - 255 255
21 Filter 3rd Cartridge Scroll Factor 2 0 - 255 255
22 Filter 3rd Cartridge Scroll Factor 3 0 - 255 255
23 Filter 3rd Cartridge Scroll Factor 4 0 - 255 255
24 Filter 3rd Cartridge Scroll Factor 5 0 - 255 255
25 Filter 3rd Cartridge Scroll Factor 6 0 - 255 255
26 Filter 3rd Cartridge Scroll Factor 7 0 - 255 255
27 Filter 3rd Cartridge Scroll Factor 8 0 - 255 255
28 Filter 3rd Cartridge Scroll Factor 9 0 - 255 255
29
Filter 3rd Cartridge Scroll Factor
10
0 - 255 255
249 Pressure Sensor
0 Pressure Monitor Pressure Value (Original) [ADC] -
1 Pressure Moniture Pressure Value (Compensated)[ADC] -
2 Press Offset Offset Value -1023 - 1023 0
3 Press Calib Effective Diff Effective Range of Calibration 0 - 1023 1023
4 Press Sensor Calibration Log
Calibration LOg
0: Excuted and Adquate Offset Value
10:Out of Range (Mini)
20: Out of Range (Max)
99: Not executed
- 99
250 Fan Voltage Adjustment * Fan voltage adj.
0 Fan 1 Min Adjust (DAC)
DAC Output for Fan Voltage adj.
Adjust Tolerance between DAC and Fan Volt.
*Lamp Mode: Eco
0-255 84
1 Fan 1 Max Adjust (DAC) 0-255 237
2 Fan 2 Min Adjust (DAC) 0-255 83
3 Fan 2 Max Adjust (DAC) 0-255 240
4 Fan 3 Min Adjust (DAC) 0-255 40
5 Fan 3 Max Adjust (DAC) 0-255 244
6 Fan 4 Min Adjust (DAC) 0-255 40
7 Fan 4 Max Adjust (DAC) 0-255 230
8 Fan 5 Min Adjust (DAC) 0-255 41
9 Fan 5 Max Adjust (DAC) 0-255 232
10 Fan 6 Min Adjust (DAC) 0-255 43
11 Fan 6 Max Adjust (DAC) 0-255 233
12 Fan 7 Min Adjust (DAC) 0-255 39
13 Fan 7 Max Adjust (DAC) 0-255 229
252 Fan Option
1 Safety Switch Safety Application use 0-6 0
2 Fan Manual Switch Fan Manual SW (0: Auto 1: Manual) 0-1 0
3 Fan1 Manual Voltage
Manual Adjustment Mode (0.1V)
*Effective only when Manual SW is 1.
0-255 100
4 Fan2 Manual Voltage 0-255 100
5 Fan3 Manual Voltage 0-255 100
6 Fan4 Manual Voltage 0-255 100
7 Fan5 Manual Voltage 0-255 100
8 Fan6 Manual Voltage 0-255 100
9 Fan7 Manual Voltage 0-255 100
10 Angle Data A Angle Data A (Read only) - -
11 Angle Data B Angle Data B (Read only) - -
12 Press Data Air Pressure Data (Read only) - -
