Sanyo plc-xu4001 User Manual

30
&RPSXWHU,QSXW
PC adjust Menu
0DQXDO3&$GMXVWPHQW
Some computers employ special signal formats which may not be tuned by Multi-scan system of this
projector. Manual PC Adjustment enables you to precisely adjust several parameters to match those
signal formats. The projector has 10 independent memory areas to store those parameters manually
adjusted. It allows you to recall the setting for a specific computer.
1
2
Use the Point ŻŹ buttons to adjust the value,
eliminating a flicker from the image displayed
(from 0 to 31).
)LQHV\QF
Use the Point ŻŹ buttons to adjust the
number of total dots in one horizontal period to
match your PC image.
7RWDOGRWV
Use the Point ŻŹ buttons to adjust the
horizontal picture position.
+RUL]RQWDO
Use the Point ŻŹ buttons to adjust the
vertical picture position.
Vertical
Use the Point ŻŹ buttons to adjust the clamp
level. When the image has dark bars, try this
adjustment.
Clamp
Press the MENU button to display the
2Q6FUHHQ0HQX8VHWKH3RLQWŸź
buttons to select PC adjust and then press
the Point Źbutton or the SELECT button.
8VHWKH3RLQWŸźEXWWRQVWRVHOHFWWKH
desired item and then press the SELECT
button to display the adjustment dialog box.
Use the Point ŻŹ buttons to adjust the
setting value.
Use the Point ŻŹ buttons to adjust the vertical
area displayed by this projector.
'LVSOD\DUHD9
Use the Point ŻŹ buttons to adjust the
horizontal area displayed by this projector.
'LVSOD\DUHD+
Press the SELECT button to show +V\QF
IUHT and 9V\QFIUHTof the connected
computer.
Current mode
