-35-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
6 DIMMER_CTRL_LEVEL7
Luminance Level 7 Data for Dimmer: Dim
Level 7 at the less than the Value
61 0 - 255
7 DIMMER_CTRL_LEVEL8
Luminance Level 8 Data for Dimmer: Dim
Level 8 at the less than the Value
70 0 - 255
8 DIMMER_CTRL_LEVEL9
Luminance Level 9 Data for Dimmer: Dim
Level 9 at the less than the Value
79 0 - 255
9 DIMMER_CTRL_LEVEL10
Luminance Level 10 Data for Dimmer: Dim
Level 10 at the less than the Value
88 0 - 255
10 DIMMER_CTRL_LEVEL11
Luminance Level 11 Data for Dimmer: Dim
Level 11 at the less than the Value
96 0 - 255
11 DIMMER_CTRL_LEVEL12
Luminance Level 12 Data for Dimmer: Dim
Level 12 at the less than the Value
105 0 - 255
12 DIMMER_CTRL_LEVEL13
Luminance Level 13 Data for Dimmer: Dim
Level 13 at the less than the Value
255 0 - 255
13 DIMMER_CTRL_LEVEL14
Luminance Level 14 Data for Dimmer: Dim
Level 14 at the less than the Value
255 0 - 255
14 DIMMER_CTRL_LEVEL15
Luminance Level 15 Data for Dimmer: Dim
Level 15 at the less than the Value
255 0 - 255
15 DIMMER_AVERAGE_POINT Luminance Data Avarage Point for Mimmer 4 0 - 16
16 DIMMER_AVERAGE_DATA Luminance Data Avarage Value for Dimmer - - * Read only
17 DIMMER_LEVEL_AUTO Current Dimmer Leverl - - * Read only
18 DIMMER_LEVEL_NORMAL Normal Dimmer Level 12 0 - 15
19 DIMMER_LEVEL_ECO Eco Dimmer Level 0 0 - 15
20 Lamp check enable 1
0: Lamp Failure Detection OFF (White 50%
Back), 1 : ON (Blue 100% Back)
21 VOLTAGE_LEVEL Lamp Voltage Unit: 8bit(Raw Data) * Read only
Group 250 FAN Cntorol XW55A / XW50A
Normal Ceiling
Normal-
HiLand
Ceiling-
HiLand
0 FAN_TEMP_A_WARNING
Temperature A to judge the Temp. Failure
Outside
39 / 43 40 / 44 34 / 33 34 / 34
30-100 (Memorized)
1 FAN_TEMP_B_WARNING
Temperature B to judge the Temp. Failure
Panel
63 / 66 64 / 67 52 / 52 56 / 58
30-100 (Memorized)
2 FAN_TEMP_C_WARNING
Temperature C to judge the Temp. Failure
Lamp
72 / 75 73 / 76 64 / 64 67 / 66
30-100 (Memorized)
3 FAN_TEMP_B A_WARNING
Temperature B-A to judge the Temp. Failure
Filter Cloggled
100/100 100/100 100/100 100/100 0-100
(Memorized)
4 FAN_TEMP_C A_WARNING
Temperature C-A to judge the Temp. Failure
Filter Cloggled
100/100 100/100 100/100 100/100 0-100
(Memorized)
5 FAN__SPEED_MONI Fan Speed Monitor - - - - - * Read only
6 FAN__SPEED_MONI Fan Speed Monitor - - - - * Read only
7 FAN_TEMP_A_MONI Temp. Sensor Monitor - - - - * Read only
8 FAN_TEMP_B_MONI Temp. Sensor Monitor - - - - * Read only
9 FAN_TEMP_C_MONI Temp. Sensor Monitor - - - - * Read only
10 Lamp Mode Normal/Auto/Eco 1 / 1 0-2 0:Normal, 1: Auto, 2: Eco
11 Fan Ctrl Mode Normal/Ceiling Switch 0 / 0 0-1 0: Normal, 1: Ceiling
12 Fan Switch Auto/Max/Min/Manual Switch 0 / 0 0-3 0: Auto 1: Max 2:Min 3: Manual
13 Hi-Land Switch Hi-Land Switch 0 / 0 0-5
0: Normal Mode , 1: High-land Mode
2˜4: High-land Mode1 ˜ 3, 5: Fixed(13.5V)
14 Safety Switch FAN Control 0 / 0 0-4 * Test Purpose
15 Fan1 Manual Voltage
Manual Adjustment Mode at FAN_CON
-
TROL_SW=3
130 / 130
0-255
16 Fan2 Manual Voltage
Manual Adjustment Mode at FAN_CON
-
TROL_SW=3
130 / 130
0-255
17
TEMP_U PWARNIN G_T IME_A
(OUTSIDE)
Raise Temp Failure Value for X minutes after
Power ON
3 / 3
0-5
18
TEMP_U PWARNIN G_T IME_B
(PANEL)
Raise Temp Failure Value for X minutes after
Power ON
3 / 3
0-5
19
TEM P_UP WARN ING_ TIME _C
(LAMP)
Raise Temp Failure Value for X minutes after
Power ON
3 / 3
0-5
20 TEMP_UPWARNING_TIME_B-A
Raise Temp Failure Value for X minutes after
Power ON
3 / 3
0-5
21 TEMP_UPWARNING_TIME_C-A
Raise Temp Failure Value for X minutes after
Power ON
3 / 3
0-5
22
UPWARNING_TEMP_A (OUT
-
SIDE)
Raise Temp Failure Value for a certain
minutes after Power ON
5 / 5
?
23 UPWARNING_TEMP_B (PANEL)
Raise Temp Failure Value for a certain
minutes after Power ON
5 / 5
?
24 UPWARNING_TEMP_C (LAMP)
Raise Temp Failure Value for a certain
minutes after Power ON
5 / 5
?
25 UPWARNING_TEMP_B-A
Raise Temp Failure Value for a certain
minutes after Power ON
5 / 5
?
26 UPWARNING_TEMP_C-A
Raise Temp Failure Value for a certain
minutes after Power ON
5 / 5
?
27 FAN_1_START_SPEED FAN1 Start Voltage 8V Unit VX10 55 / 45 0-255
28 FAN_2_START_SPEED FAN2 Start Voltage 8V Unit VX10 65 / 65 0-255
31 FAN_1_COOLING_SPEED FAN1 Voltage at Power OFF (Fan Mode L1) 100 / 100 0-255
32 FAN_2_COOLING_SPEED FAN2 Voltage at Power OFF (Fan Mode L1) 100 / 100 0-255
33 FAN_1_TEMPERROR_SPEED FAN1 Voltage at Temp. Failure 130 / 130 0-255
