10
Part Names and Functions
Top Control
qwer
t y u i
i INPUT button
Select an input source (p.24).
t MENU button
Open or close the On-Screen Menu (p.20).
e WARNING indicator
Emits a red light when the projector detects an abnormal
condition. It also blinks red when the internal
temperature of the projector exceeds the operating
range (p.41, 49).
w
POWER indicator
- Lights red while the projector is in stand-by mode.
- Lights green during operations.
- Blinks red during the cooling-off period.
- Blinks green in the Power management mode (p.37).
When the automatic slide shutter is closed during
operations, it blinks orange (p.49).
u POINT
eedd77 88
buttons
Select an item or adjust the setting values in the On-
Screen Menu, or use them to pan the image in the
Normal through mode (p.34).
y OK button
Execute the item selected or use it to access the sub-
menu items (p.20).
r LAMP REPLACE indicator
Emits a yellow light when the life of the projection lamp
draws to an end (p.46, 49).
q POWER ON-OFF button
Turn the projector on or off (p.18, 19).
