Sanyo STW-2 Series - Removing Electric Heater

52
(3) Disconnect the wiring connectors and lead wires
connecting the electrical parts in the electrical
junction box. (Figs. 5 and 6)
9-4. Removing Electric Heater
(1) Remove the 4 screws holding the air outlet frame
ass'y. (Fig. 7)
(2) Remove the 2 screws holding the electric heater.
(Fig. 8)
(3) Lift the electric heater up out of the unit. (Fig. 8)
Fig. 8
Electric
heater
Fig. 7
Air outlet frame ass´y
Fig. 6
Fig. 5
Electrical
junction box
