RATING CAPACITY: 7,100 BTU/h AIR FLOW RATE: 315 CFM
EVAPORATOR CONDENSER
ENT. TEMP. °F (°C) AMBIENT TEMP. °F (°C)
W.B. D.B. 75 85 95 105 115
(23.9) (29.4) (35.0) (40.6) (46.1)
TC 7,190 6,840 6,450 6,000 5,500
CI 0.41 0.45 0.49 0.55 0.61
72 (22.2) SHC 6,220 6,060 5,880 5,690 5,470
59 76 (24.4) SHC 7,190 6,840 6,450 6,000 5,500
(15.0) 80 (26.7) SHC 7,190 6,840 6,450 6,000 5,500
84 (28.9) SHC 7,190 6,840 6,450 6,000 5,500
88 (31.1) SHC 7,190 6,840 6,450 6,000 5,500
TC 7,460 7,130 6,770 6,370 5,930
CI 0.41 0.45 0.5 0.56 0.62
72 (22.2) SHC 5,050 4,910 4,760 4,600 4,430
63 76 (24.4) SHC 6,070 5,930 5,790 5,630 5,450
(17.2) 80 (26.7) SHC 7,140 7,000 6,770 6,370 5,930
84 (28.9) SHC 7,460 7,130 6,770 6,370 5,930
88 (31.1) SHC 7,460 7,130 6,770 6,370 5,930
TC 7,750 7,440 # 7,100 6,720 6,310
CI 0.42 0.46 0.5 0.57 0.63
72 (22.2) SHC 3,880 3,760 3,630 3,490 3,340
67 76 (24.4) SHC 4,900 4,780 4,660 4,520 4,370
(19.4) 80 (26.7) SHC 5,970 5,850 5,730 5,590 5,440
84 (28.9) SHC 6,990 6,880 6,750 6,610 6,310
88 (31.1) SHC 7,750 7,440 7,100 6,720 6,310
TC 8,160 7,870 7,570 7,230 6,870
CI 0.42 0.46 0.51 0.57 0.64
72 (22.2) SHC 2,690 2,590 2,490 2,370 2,250
71 76 (24.4) SHC 3,720 3,620 3,510 3,400 3,280
(21.7) 80 (26.7) SHC 4,790 4,690 4,580 4,470 4,350
84 (28.9) SHC 5,810 5,710 5,610 5,490 5,370
88 (31.1) SHC 6,830 6,730 6,630 6,520 6,390
TC 8,320 8,050 7,770 7,440 7,090
CI 0.43 0.47 0.52 0.58 0.65
75 76 (24.4) SHC 2,490 2,400 2,320 2,220 2,110
(23.9) 80 (26.7) SHC 3,560 3,470 3,390 3,290 3,180
84 (28.9) SHC 4,580 4,500 4,410 4,310 4,210
88 (31.1) SHC 5,610 5,520 5,440 5,330 5,230
TC : Total Cooling Capacity (BTU/h)
SHC: Sensible Heat Capacity (BTU/h)
CI : Compressor Input (kW)
Rating conditions are
M.R.= 1.25 US pints/h
: Outdoor Ambient Temp. 95°F DB
: Indoor Unit Entering Air Temp. 80°F DB / 67°F WB
