WARMER
COOLER
r
a
n
g
e
I
n
t
e
r
m
e
d
i
a
t
e
7
2
°F
(88°F)
(55°F)
Thermostat
Mode
selector
switch
Thermostat Control
The thermostat knob is used to control the room temperature. The unit automatically
cycles on and off to maintain room temperature. A comfortable temperature will be
maintained in most rooms when the control is set to about intermediate range.
Mode Selector Switch
HI HEAT provides heating with high fan speed operation.
LOW HEAT provides heating with low fan speed operation.
OFF setting stops heating or cooling operation.
FAN provides fan operation without cooling or heating.
LO COOL provides cooling with low fan speed operation.
HI COOL provides cooling with high fan speed operation.
As long as power is connected to the unit, freeze protection always
functions at any position even at OFF position.
( See 10-3. Freeze Protection for detail)
NOTE
Cooling & Electric Heating Models
Heat Pump Models
