33
Included in the Kit
Surface Mount
Kit will be labeled: D-MK-WLL-PLTC-1
• 4 - 6-32 x 1” Machine Flat Screws
• 4 - 6-19 x 1/2” Flat Head Screws
• 4 - 8-32 x 7/19” Screws
• 2 - 8-32 x 7/16” Screws
Below is a list of all the items included in the SBP 3000 installation kit. The items in the kit will correspond to the type of mounting option chosen.
Flush Mount
Kit will be labeled: D-MK-3-IP-F
• 1 - Grounding Wire, Loop End (18 AWG), Green
• 1 - 24VAC Power Harness (18 AWG), Black, Green, White
• 4 - Machine Flat Screws 6-32 x 1/2”, Black
• 1 - 6-32 Hex Machine Screw Nut
• 1 - Internal Tooth Lockwasher #6
Installation
