The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
P. (+1) 215.322.6063
F. (+1) 215.322.8498
www.sapling-inc.com
Wall Mount Installation
11) Place the filter over the display board. You
should hear a snapping noise as the latches drop
into place.
10) Remove the plastic cover from the display board.
12) Place the housing frame onto the housing. You
should hear a snapping noise as the latches drop
into place.
13) Power the clock if you have not already done
so. After testing the LED segments and presenting
some diagnostic information, the clock will display
the time based off if its internal quartz oscillator. It
will correct itself to show synchronized time as soon
as it receives data from an NTP server.
