Model BP 4100 S BP 3100 S BP 3100 P
Weighing range structure SuperRange SuperRange PolyRange
Weighing capacity g 4,100 3,100 600/1,200/
3,100
Readability g 0.01 0.01 0.01/0.02/
0.05
Tare range (by subtraction) g –4,100 –3,100 –3,100
Reproducibility (standard deviation)* g ≤±0.01 ≤±0.01 ≤±0.01/
0.01/0.03
Linearity g ≤±0.02 ≤±0.02 ≤±0.02/
0.02/0.05
Response time (average) s ≤1.5
Allowable ambient operating temperature °C 0 ... +40
Operating temperature range °C +10 ... +30
Sensitivity drift within +10 °C ... +30 °C /°C ≤±2·10
–6
Pan size mm 180 x 180
Dimensions (WxDxH) mm 204 x297x81
Net weight, approx. kg 3.1
External calibration weight
(of at least accuracy class...) g 2,000 (F1) 2,000 (F1) 1,000 (F1)
Power requirements V~ Via AC adapter: STNG 6, 230 VAC or 115 VAC,
–20% ... +15% (IP 20 protection)
Frequency Hz 48– 63
Power consumption (average) VA 16 maximum; 8 average
Hours of operation with fully charged
YRB 05 Z external battery pack, approx. h 25
Built-in interface RS-232C-S/V24-V28; 7-bit; parity: even, mark, odd, space;
transmission rates: 150...19,200 baud;
1or 2 stop bits; software/hardware handshake
Standard features/equipment supplied:
AC adapter, varies acc. to country x x x
Level indicator x x x
Hanger for below-balance weighing x x x
* = standard deviation of the reproducibility acc. to DIN 8120, Part 3
72
