Model BP 610 BP 410
Weighing capacity g 610 410
Readability g 0.01 0.01
Tare range (by subtraction) g – 610 – 410
Reproducibility (standard deviation)* g ≤±0.01 ≤±0.01
Linearity g ≤±0.01 ≤±0.01
Response time (average) s ≤1
Allowable ambient operating temperature °C 0 ... +40
Operating temperature range °C +10 ... +30
Sensitivity drift within +10 °C ... +30 °C /°C ≤±5 ·10
–6
Pan size mm Ø 115
Dimensions (WxDxH) mm 204 x297x80
Net weight, approx. kg 1.9
External calibration weight
(of at least accuracy class...) g 500 (F2) 200 (F2)
Power requirements V~ Via AC adapter: STNG 6, 230 VAC or 115 VAC,
–20% ... +15% (IP 20 protection)
Frequency Hz 48– 63
Power consumption (average) VA 16 maximum; 8 average
Hours of operation with fully charged
YRB 05 Z external battery pack, approx. h 45
Built-in interface RS-232C-S/V24-V28; 7-bit; parity: even, mark, odd, space;
transmission rates: 150...19,200 baud;
1or 2 stop bits; software/hardware handshake
Standard features/equipment supplied:
AC adapter, varies acc. to country x x
Level indicator x x
Hanger for below-balance weighing x x
* = standard deviation of the reproducibility acc. to DIN 8120, Part 3
71
