16 Operating Instructions EVO1S1 | SPO1S1
Installation
4.3 Assembling the Scale
Inserting the Weighing Pan
t Place the weighing pan onto the scale from above.
4.4 Power Supply
The scale is normally powered via the USB connection of your PC, which also supplies
data for the scale. If this USB connection is not available, you can use AC adapter
YPS06-USB (see Chapter “12 Accessories”, page 33) for the power supply, which
comes with different, country-specific mains adapters. The assembly is described in
the following.
4.4.1 AC Adapter Assembly (optional)
Using the wrong mains adapter may cause fatal electric shock and damage the
equipment.
Never plug the mains adapter into the socket when it is disconnected from the AC
adapter (danger of electrical shock).
t Use the right mains adapter for your mains power supply.
Mains adapter set YAK01
Bag Region/Country
a) transparent Europe/EU (except United Kingdom)
b) blue USA
c) yellow United Kingdom
Mains adapter set YAK02
d) red Australia
e) turquoise South Africa
f) white Argentina
g) pink Brazil
