Sartorius FB - Page 87

87
Model FB16EDE-S, FB34EDE-P, FB12EDE-P, FB64EDE-S,
FB16EDE-S0UR* FB34EDE-P0UR* FB12EDE-P0UR* FB64EDE-S0UR*
Readability g 0.1 0.1/0.2/0.5 0.1/0.2 1
Weighing capacity kg 16 8/16/34 6/12 64
Max. overload capacity kg 130 130 130 130
Tare range (by subtraction) kg – 16 – 34 – 12 – 64
Preload that can be electronically kg 4 – 3 –
compensated for (without restricting
the weighing capacity)
Max. preload at the beginning kg 18 18 15 32
of calibration/adjustment (scale display
does not have to be zeroed)
Repeatability ≤±g 0.1 0.1/0.2/0.5 0.1/0.2 1
Linearity ≤±g 0.2 0.2/0.2/0.5 0.2 2
Sensitivity drift
between +10 ... +30 °C ≤±/K 2 · 10
-6
2 · 10
-6
2 · 10
-6
3 · 10
-6
Response time (average) s 1.5 1.5 1.5 1
External standard calibration weight kg 10 (F1) 10 (F2) 10 (F1) 10 (F2)
(at least of the accuracy class indicated)
Load plate size mm 307 x 417
Net weight, approx. kg 15.8
Dust and water protection rating of the
scale housing acc. to EN 60529 IP65
* = U.S./Canadian Keypad version
Overview
