Table 4-1 User Assignable Registers
Register contents Address Size, byte Direction Range
User definable data 0 0
c c c
User definable data 1 1
c c c
User definable data 2
...
2
...
c
...
c
...
c
...
User definable data 119 119
c c c
c - depends on the mapped register
Table 4-2 User Assignable Register Map
Register contents Address Size, byte Direction Range
Register address for user data 0 120 2 R/W 240 to 9999
Register address for user data 1 121 2 R/W 240 to 9999
Register address for user data 2
...
122
...
2
...
R/W
...
240 to 9999
...
Register address for user data
119
239 2 R/W 240 to 9999

Satec PM130 Specifications

General

Frequency Measurement Range	45 to 65 Hz
Power Supply	85-265V AC/DC, 100-300V DC
Display	LCD
Communication	RS485
Digital Inputs	2
Digital Outputs	2
Protocols	Modbus RTU
Accuracy	0.2% of reading
Power Accuracy	0.5%
