Parameter Add- Size, Direc- Unit
Scale
c
Con-
ress byte tion Low High version
-kvarh net (low)
e
(E) 293 2 R/W kvarh 0 9999 NONE
-kvarh net (high)
e
(E) 294 2 R/W kvarh x10
4
0 999 x10
4
Reserved 295 2 R
Reserved 296 2 R
Reserved 297 2 R
Reserved 298 2 R
Reserved 299 2 R
Reserved 300 2 R
kVAh (low) (E) 301 2 R/W kVAh 0 9999 NONE
kVAh (high) (E) 302 2 R/W kVAh x10
4
0 9999 x10
4
Present sliding window
kW demand
f
(E)
303 2 R kW -Pmax Pmax LIN3
Present sliding window
kVA demand
f
(E)
304 2 R kVA -Pmax Pmax LIN3
PF at maximum siding
window kVA demand (E)
305 2 R 0.001 -1.000 1.000 LIN3
Reserved 306 2 R
Reserved 307 2 R
Reserved 308 2 R
c
The parameter limits are as follows:
Vmax
(690 V input option) = 828V @ PT Ratio = 1
Vmax
(690 V input option) = 144 × PT Ratio [V] @ PT Ratio > 1
Vmax
(120 V input option) =144 × PT Ratio [V]
Imax
(50% over-range) = 1.5 × CT primary current [A]
Pmax
= (Imax × Vmax × 3)/1000 [kW] if wiring mode is 4LN3 or 3LN3
Pmax
= (Imax × Vmax × 2)/1000 [kW] if wiring mode is 4LL3, 3OP2, 3DIR2, 3OP3 or 3LL3
d
Positive readings of kvarh net
e Negative readings of kvarh net
f
To get block interval demand readings, specify the number of demand periods equal to 1
(see Table 5-2)
g
When the 4LN3 or 3LN3 wiring mode is selected, the voltages will be line-to-neutral; for any
other wiring mode, they will be line-to-line voltages.
(P) available in the PM130P and PM130E
(E) available in the PM130E
NOTE
Writing a zero to one of registers 280-286 causes reset of all maximum demands.
Writing a zero to one of registers 287-294 and 301-302 causes reset of all accumulated
energies.
5.2 Basic Setup
Table 5-2 Basic Setup Registers
Parameter Add-
ress
Size,
byte
Direc-
tion
Range
Wiring mode
c
2304 2 R/W 0 = 3OP2, 1 = 4LN3,
2 = 3DIR2, 3 = 4LL3,
4 = 3OP3, 5 = 3LN3,
6 = 3LL3
PT ratio 2305 2 R/W
10 to 65000 × 0.1
CT primary current 2306 2 R/W 1 to 50000 A
