5.6 Instrument Status
Table 5-6 Instrument Status Registers
Parameter Address Size, Direc
-
Unit Range
byte tion
Instrument reset
register
c
2560 2 R/W 0 (when read)
65535 (when written) =
reset the instrument
Reserved 2561 2 R Read as 0
Relay status 2562 2 R see Table 5-7
Reserved 2563 2 R Read as 0
Reserved 2564 2 R
Firmware version
number
2565 2 R 0-65535
Instrument options 1 2566 2 R see Table 5-8
Instrument options 2 2567 2 R see Table 5-8
c
Writing a value of 65535 into register 2560 will cause the instrument to perform a warm
restart.
Table 5-7 Relay Status
Bit number Description
0-6 Not used (permanently set to 1)
7 Relay status
8-15 Not used (permanently set to 0)
Bit meaning: 0 = relay operated, 1 = relay released
Table 5-8 Instrument Options
Options register Bit Description
Options1
0
120V option
1
690V option
2-4
Reserved
5
150% current over-range
6-8
Reserved
9
Relays option
10-15
Reserved
Options 2
0-2
Number of relays - 1
3-15
Reserved
5.7 Extended Status
Table 5-9 Extended Status Registers
Register description Addres
s
Size,
byte
Direction Value range
Relay status 3452 2 R see Table 5-10
Reserved 3453- 2 R Read as 0
3454 2
Setpoints status 3455 2 R see Table 5-11
Log status 3456 2 R see Table 5-12
Reserved 3457-
3473
2 R Read as 0
Setpoint alarm status 3474 2 R/W see Table 5-13
Self-check alarm status 3475 2 R/W see Table 5-14

Satec PM130 Specifications

General

Frequency Measurement Range	45 to 65 Hz
Power Supply	85-265V AC/DC, 100-300V DC
Display	LCD
Communication	RS485
Digital Inputs	2
Digital Outputs	2
Protocols	Modbus RTU
Accuracy	0.2% of reading
Power Accuracy	0.5%
