Satec PM130 - Powermeter Register Descriptions; Basic Data Registers

13
5 POWERMETER REGISTERS DESCRIPTION
5.1 Basic Data Registers
Table 5-1 Basic Data Registers
Parameter Add- Size, Direc- Unit
Scale
c
Con-
ress byte tion Low High version
Voltage L1/L12
g
256 2 R V 0 Vmax LIN3
Voltage L2/L23
g
257 2 R V 0 Vmax LIN3
Voltage L3/L31
g
258 2 R V 0 Vmax LIN3
Current L1 259 2 R A 0 Imax LIN3
Current L2 260 2 R A 0 Imax LIN3
Current L3 261 2 R A 0 Imax LIN3
kW L1 (P) 262 2 R kW -Pmax Pmax LIN3
kW L2 (P) 263 2 R kW -Pmax Pmax LIN3
kW L3 (P) 264 2 R kW -Pmax Pmax LIN3
kvar L1 (P) 265 2 R kvar -Pmax Pmax LIN3
kvar L2 (P) 266 2 R kvar -Pmax Pmax LIN3
kvar L3 (P) 267 2 R kvar -Pmax Pmax LIN3
kVA L1 (P) 268 2 R kVA -Pmax Pmax LIN3
kVA L2 (P) 269 2 R kVA -Pmax Pmax LIN3
kVA L3 (P) 270 2 R kVA -Pmax Pmax LIN3
Power factor L1 (P) 271 2 R 0.001 -1.000 1.000 LIN3
Power factor L2 (P) 272 2 R 0.001 -1.000 1.000 LIN3
Power factor L3 (P) 273 2 R 0.001 -1.000 1.000 LIN3
Total power factor (P) 274 2 R 0.001 -1.000 1.000 LIN3
Total kW (P) 275 2 R kW -Pmax Pmax LIN3
Total kvar (P) 276 2 R kvar -Pmax Pmax LIN3
Total kVA (P) 277 2 R kVA -Pmax Pmax LIN3
Neutral current 278 2 R A 0 Imax LIN3
Frequency 279 2 R 0.01 Hz 45.00 65.00 LIN3
Maximum sliding
window kW demand
f
(E)
280 2 R/W kW -Pmax Pmax LIN3
Accumulated kW
demand (E)
281 2 R/W kW -Pmax Pmax LIN3
Maximum sliding
window kVA demand
f
(E)
282 2 R/W kVA -Pmax Pmax LIN3
Accumulated kVA
demand (E)
283 2 R/W kVA -Pmax Pmax LIN3
Max. ampere demand
L1
284 2 R/W A 0 Imax LIN3
Max. ampere demand
L2
285 2 R/W A 0 Imax LIN3
Max. ampere demand
L3
286 2 R/W A 0 Imax LIN3
kWh import (low) (E) 287 2 R/W kWh 0 9999 NONE
kWh import (high) (E) 288 2 R/W kWh x10
4
0 9999 x10
4
kWh export (low) (E) 289 2 R/W kWh 0 9999 NONE
kWh export (high) (E) 290 2 R/W kWh x10
4
0 9999 x10
4
+kvarh net (low)
d
(E) 291 2 R/W kvarh 0 9999 NONE
+kvarh net (high)
d
(E) 292 2 R/W kvarh x10
4
0 9999 x10
4
