Satec PM130 User Manual

24
Parameter 16-bit Register 32-bit Data Dir. Unit
d
Range/Scale
c
Reg. Conv. Register ID Low High
Total kvar 8777 LIN3 18562-18563 13569 R kvar -Pmax Pmax
Total kVA 8778 LIN3 18564-18565 13570 R kVA 0 Pmax
Total PF
e
8779 LIN3 18566-18567 13571 R 0.001 0 1.000
Maximum real-time auxiliary values (M)
Reserved 8816 18688-18689 13824 R 0
Neutral current (P) 8817 LIN3 18680-18681 13825 R A 0 Imax
Frequency (P)
d
8818 LIN3 18682-18683 13826 R 0.01Hz 0 100.00
Maximum demands (M)
Max. volt demand L1/L12 (P)
g
8856 LIN3 18816-18817 14080 R V 0 Vmax
Max. volt demand L2/L23 (P)
g
8857 LIN3 18818-18819 14081 R V 0 Vmax
Max. volt demand L3/L31 (P)
g
8858 LIN3 18820-18821 14082 R V 0 Vmax
Max. ampere demand L1 8859 LIN3 18822-18823 14083 R A 0 Imax
Max. ampere demand L2 8860 LIN3 18824-18825 14084 R A 0 Imax
Max. ampere demand L3 8861 LIN3 18826-18827 14085 R A 0 Imax
Reserved 8862 18828-18829 14086 R 0 0
Reserved 8863 18830-18831 14087 R 0 0
Reserved 8864 18832-18833 14088 R 0 0
Max. sliding window kW
demand (E)
8865 LIN3 18834-18835 14089 R kW 0 Pmax
Reserved 8866 18836-18837 14090 R 0 0
Max. sliding window kVA
demand (E)
8867 LIN3 18838-18839 14091 R kVA 0 Pmax
c
For the parameter limits, see note
c
to Table 5-1
d
The actual frequency range is 45.00 - 65.00 Hz
e
Absolute min/max value (lag or lead)
f
The exported energy registers are read as positive unsigned long (32-bit) integers
g
When the 4LN3 or 3LN3 wiring mode is selected, the voltages will be line-to-neutral; for any
other wiring mode, they will be line-to-line voltages.
(M) These parameters are logged to the Min/Max log
(P) available in the PM130P and PM130E (E) available in the PM130E
5.9 Alarm/Event Setpoints
Table 5-16 Setpoint Registers
Setpoint Setup registers (see Table 5-17)
Setpoint #1 2576-2583
Setpoint #2 2584-2591
Setpoint #3 2592-2599
Setpoint #4 2600-2607
Setpoint #5 2608-2615
Setpoint #6 2616-2623
Setpoint #7 2624-2631
Setpoint #8 2632-2639
Setpoint #9 2640-2647
Setpoint #10 2648-2655
Setpoint #11 2656-2663
Setpoint #12 2664-2671
Setpoint #13 2672-2679
Setpoint #14 2680-2687
Setpoint #15 2688-2695
Setpoint #16 2696-2703
