Table 5-24 Relay Operation Status
Operation status Value
Normal operation 0
Force operate 1
Force release 2
5.12 Min/Max Log
The Min/Max log registers are supported only for compatibility with other models of instruments.
Because the Min/Max log is not time stamped in the PM130, reading these registers returns you
only values of the Min/Max log parameters which you can read directly via extended data
registers (see Table 5-15).
Table 5-25 Min/Max Log Windows Registers
Min/Max log window Registers (see Table 5-26)
Min/Max log window #1 4174-4181
Min/Max log window #2 4182-4189
Min/Max log window #3 4190-4197
Min/Max log window #4 4198-4205
Min/Max log window #5 4206-4213
Min/Max log window #6 4214-4221
Min/Max log window #7 4222-4229
Min/Max log window #8 4230-4237
Min/Max log window #9 4238-4245
Min/Max log window #10 4246-4253
Min/Max log window #11 4254-4261
Min/Max log window #12 4262-4269
Table 5-26 Min/Max Log Window Registers
Parameter Offset Size,
byte
Direction Range
Second +0 2 R 0
Minute +1 2 R 0
Hour +2 2 R 0
Day +3 2 R 0
Month +4 2 R 0
Year +5 2 R 0
Parameter value
c
+6
+7
4 R see Table 5-15
c
The Min/Max parameter value can be read in one or two registers depending on the value
type. For the value length and conversion scales, refer to Table 5-15. The time stamp is not
available in the PM130 and is read as zeros.
Table 5-27 Min/Max Log Mapping Register
Parameter Address Size,
byte
Direction Range
Min/Max log start parameter
ID for window #1
4172 2 R/W see Table 5-15
From 1 to 12 adjacent Min/Max log records can be read at a time via the Min/Max log windows. The
starting window #1 can be mapped to any Min/Max log parameter listed in Table 5-15 by writing the
parameter ID to the Min/Max log mapping register. This must be written before reading the Min/Max log
windows. Note that through Min/Max log windows, you can read only adjacent parameters within the same
Min/Max log data group. Reading parameters outside of the selected Min/Max log data group will return
zero.

Satec PM130 Specifications

General

Frequency Measurement Range	45 to 65 Hz
Power Supply	85-265V AC/DC, 100-300V DC
Display	LCD
Communication	RS485
Digital Inputs	2
Digital Outputs	2
Protocols	Modbus RTU
Accuracy	0.2% of reading
Power Accuracy	0.5%
