Satec PM130 User Manual

23
Parameter 16-bit Register 32-bit Data Dir. Unit
d
Range/Scale
c
Reg. Conv. Register ID Low High
kWh import L2 7618
7619
14850-14851 6145 R kWh 0 10
8
-1
kWh import L3 7620
7621
14852-14853 6146 R kWh 0 10
8
-1
kvarh import L1 7622
7623
14854-14855 6147 R kvarh 0 10
8
-1
kvarh import L2 7624
7625
14856-14857 6148 R kvarh 0 10
8
-1
kvarh import L3 7626
7627
14858-14859 6149 R kvarh 0 10
8
-1
kVAh total L1 7628
7629
14860-14861 6150 R kVAh 0 10
8
-1
kVAh total L2 7630
7631
14862-14863 6151 R kVAh 0 10
8
-1
kVAh total L3 7632
7633
14864-14865 6152 R kVAh 0 10
8
-1
Reserved
Reserved 8296
...
8313
17024-17025
...
17058-17059
10496
...
10513
R 0 0
Reserved
Reserved 8336
...
8339
17152-17153
...
17158-17159
10752
...
10755
R 0 0
Minimum real-time values per phase (M)
Voltage L1/L12
g
8416 LIN3 17408-17409 11264 R V 0 Vmax
Voltage L2/L23
g
8417 LIN3 17410-17411 11265 R V 0 Vmax
Voltage L3/L31
g
8418 LIN3 17412-17413 11266 R V 0 Vmax
Current L1 (P) 8419 LIN3 17414-17415 11267 R A 0 Imax
Current L2 (P) 8420 LIN3 17416-17417 11268 R A 0 Imax
Current L3 (P) 8421 LIN3 17418-17419 11269 R A 0 Imax
Minimum real-time total values (M) (P)
Total kW 8456 LIN3 17536-17537 11520 R kW -Pmax Pmax
Total kvar 8457 LIN3 17538-17539 11521 R kvar -Pmax Pmax
Total kVA 8458 LIN3 17540-17541 11522 R kVA 0 Pmax
Total PF
e
8459 LIN3 17542-17543 11523 R 0.001 0 1.000
Minimum real-time auxiliary values (M)
Reserved 8496 17664-17665 11776 R 0 0
Neutral current (P) 8497 LIN3 17666-17667 11777 R A 0 Imax
Frequency (P)
d
8498 LIN3 17668-17669 11778 R 0.01Hz 0 100.00
Minimum demands (M) - Reserved
Reserved 8536
...
8547
17792-17793
...
18814-18815
12032
...
12043
R 0 0
Maximum real-time values per phase (M)
Voltage L1/L12
g
8736 LIN3 18432-18433 13312 R V 0 Vmax
Voltage L2/L23
g
8737 LIN3 18434-18435 13313 R V 0 Vmax
Voltage L3/L31
g
8738 LIN3 18436-18437 13314 R V 0 Vmax
Current L1 (P) 8739 LIN3 18438-18439 13315 R A 0 Imax
Current L2 (P) 8740 LIN3 18440-18441 13316 R A 0 Imax
Current L3 (P) 8741 LIN3 18442-18443 13317 R A 0 Imax
Maximum real-time total values (M) (P)
Total kW 8776 LIN3 18560-18561 13568 R kW -Pmax Pmax

Satec PM130 Specifications

General

Frequency Measurement Range	45 to 65 Hz
Power Supply	85-265V AC/DC, 100-300V DC
Display	LCD
Communication	RS485
Digital Inputs	2
Digital Outputs	2
Protocols	Modbus RTU
Accuracy	0.2% of reading
Power Accuracy	0.5%
