Satec PM130 User Manual

22
Parameter 16-bit Register 32-bit Data Dir. Unit
d
Range/Scale
c
Reg. Conv. Register ID Low High
Voltage unbalance (P) 7499 LIN3 14470-14471 5379 R 1% 0 300
Current unbalance (P) 7500 LIN3 14472-14473 5380 R 1% 0 300
Present demands
Volt demand L1/L12 (P)
g
7536 LIN3 14592-14593 5632 R V 0 Vmax
Volt demand L2/L23 (P) g 7537 LIN3 14594-14595 5633 R V 0 Vmax
Volt demand L3/L31 (P)
g
7538 LIN3 14596-14597 5634 R V 0 Vmax
Ampere demand L1 7539 LIN3 14598-14599 5635 R A 0 Imax
Ampere demand L2 7540 LIN3 14600-14601 5636 R A 0 Imax
Ampere demand L3 7541 LIN3 14602-14603 5637 R A 0 Imax
Block kW demand (E) 7542 LIN3 14604-14605 5638 R kW 0 Pmax
Reserved 7543 14606-14607 5639 R 0 0
Block kVA demand (E) 7544 LIN3 14608-14609 5640 R kVA 0 Pmax
Sliding window kW demand
(E)
7545 LIN3 14610-14611 5641 R kW 0 Pmax
Reserved 7546 14612-14613 5642 R 0 0
Sliding window kVA demand
(E)
7547 LIN3 14614-14615 5643 R kVA 0 Pmax
Reserved 7548 14616-14617 5644 R 0 0
Reserved 7549 14618-14619 5645 R 0 0
Reserved 7550 14620-14621 5646 R 0 0
Accumulated kW demand
(import) (E)
7551 LIN3 14622-14623 5647 R kW 0 Pmax
Reserved 7552 14624-14625 5648 R 0 0
Accumulated kVA demand 7553 LIN3 14626-14627 5649 R kVA 0 Pmax
Predicted sliding window kW
demand
7554 LIN3 14628-14629 5650 R kW 0 Pmax
Reserved 7555 14630-14631 5651 R 0 0
Predicted sliding window kVA
demand (E)
7556 LIN3 14632-14633 5652 R kVA 0 Pmax
PF at maximum sliding
window kVA demand (E)
7557 LIN3 14634-14635 5653 R 0.001 -1.000 1.000
Total energies (E)
kWh import 7576
7577
14720-14721 5888 R kWh 0 10
8
-1
kWh export
f
7578
7579
14722-14723 5889 R kWh 0 10
8
-1
Reserved 7580
7581
14724-14725 5890 R 0 0
Reserved 7582
7583
14726-14727 5891 R 0 0
kvarh import 7584
7585
14728-14729 5892 R kvarh 0 10
8
-1
kvarh export
f
7586
7587
14730-14731 5893 R kvarh 0 10
8
-1
Reserved 7588
7589
14732-14733 5894 R 0 0
Reserved 7590
7591
14734-14735 5895 R 0 0
kVAh total 7592
7593
14736-14737 5896 R kVAh 0 10
8
-1
Phase energies (E)
kWh import L1 7616
7617
14848-14849 6144 R kWh 0 10
8
-1

Satec PM130 Specifications

General

Frequency Measurement Range	45 to 65 Hz
Power Supply	85-265V AC/DC, 100-300V DC
Display	LCD
Communication	RS485
Digital Inputs	2
Digital Outputs	2
Protocols	Modbus RTU
Accuracy	0.2% of reading
Power Accuracy	0.5%
