Satec PM130 User Manual

21
Parameter 16-bit Register 32-bit Data Dir. Unit
d
Range/Scale
c
Reg. Conv. Register ID Low High
Total PF 7259 LIN3 13702-13703 3843 R 0.001 -1.000 1.000
Reserved 7260 13704-13705 3844 R 0
Reserved 7261 13706-13707 3845 R 0
Real-time auxiliary values
Reserved 7296 13824-13825 4096 R 0 0
Neutral current 7297 LIN3 13826-13827 4097 R A 0 Imax
Frequency
d
7298 LIN3 13828-13829 4098 R 0.01Hz 0 100.00
Voltage unbalance (P) 7299 LIN3 13830-13831 4099 R 1% 0 300
Current unbalance (P) 7300 LIN3 13832-13833 4100 R 1% 0 300
Average values per phase (power values - P)
Voltage L1/L12
g
7336 LIN3 13952-13953 4352 R V 0 Vmax
Voltage L2/L23
g
7337 LIN3 13954-13955 4353 R V 0 Vmax
Voltage L3/L31
g
7338 LIN3 13956-13957 4354 R V 0 Vmax
Current L1 7339 LIN3 13958-13959 4355 R A 0 Imax
Current L2 7340 LIN3 13960-13961 4356 R A 0 Imax
Current L3 7341 LIN3 13962-13963 4357 R A 0 Imax
kW L1 7342 LIN3 13964-13965 4358 R kW -Pmax Pmax
kW L2 7343 LIN3 13966-13967 4359 R kW -Pmax Pmax
kW L3 7344 LIN3 13968-13969 4360 R kW -Pmax Pmax
kvar L1 7345 LIN3 13970-13971 4361 R kvar -Pmax Pmax
kvar L2 7346 LIN3 13972-13973 4362 R kvar -Pmax Pmax
kvar L3 7347 LIN3 13974-13975 4363 R kvar -Pmax Pmax
kVA L1 7348 LIN3 13976-13977 4364 R kVA 0 Pmax
kVA L2 7349 LIN3 13978-13979 4365 R kVA 0 Pmax
kVA L3 7350 LIN3 13980-13981 4366 R kVA 0 Pmax
Power factor L1 7351 LIN3 13982-13983 4367 R 0.001 -1.000 1.000
Power factor L2 7352 LIN3 13984-13985 4368 R 0.001 -1.000 1.000
Power factor L3 7353 LIN3 13986-13987 4369 R 0.001 -1.000 1.000
Reserved 7354 13988-13989 4370 R 0 0
Reserved 7355 13990-13991 4371 R 0 0
Reserved 7356 13992-13993 4372 R 0 0
Reserved 7357 13994-13995 4373 R 0 0
Reserved 7358 13996-13997 4374 R 0 0
Reserved 7359 13998-13999 4375 R 0 0
Reserved 7360 14000-14001 4376 R 0 0
Reserved 7361 14002-14003 4377 R 0 0
Reserved 7362 14004-14005 4378 R 0 0
Reserved 7363 14006-14007 4379 R 0 0
Reserved 7364 14008-14009 4380 R 0 0
Reserved 7365 14010-14011 4381 R 0 0
Voltage L12 7366 LIN3 14012-14013 4382 R V 0 Vmax
Voltage L23 7367 LIN3 14014-14015 4383 R V 0 Vmax
Voltage L31 7368 LIN3 14016-14017 4384 R V 0 Vmax
Average total values (P)
Total kW 7456 LIN3 14336-14337 5120 R kW -Pmax Pmax
Total kvar 7457 LIN3 14338-14339 5121 R kvar -Pmax Pmax
Total kVA 7458 LIN3 14340-14341 5122 R kVA 0 Pmax
Total PF 7459 LIN3 14342-14343 5123 R 0.001 -1.000 1.000
Reserved 7460 14344-14345 5124 R 0 0
Reserved 7461 14346-14347 5125 R 0 0
Average auxiliary values
Reserved 7496 14464-14465 5376 R 0 0
Neutral current 7497 LIN3 14466-14467 5377 R A 0 Imax
Frequency
d
7498 LIN3 14468-14469 5378 R 0.01Hz 0 100.00

Satec PM130 Specifications

General

Frequency Measurement Range	45 to 65 Hz
Power Supply	85-265V AC/DC, 100-300V DC
Display	LCD
Communication	RS485
Digital Inputs	2
Digital Outputs	2
Protocols	Modbus RTU
Accuracy	0.2% of reading
Power Accuracy	0.5%
