Satec PM130 User Manual

20
Table 5-16 Extended Data Registers
Parameter 16-bit Register 32-bit Data Dir. Unit
d
Range/Scale
c
Reg. Conv. Register ID Low High
None
None 6656 11776-11777 0 R 0 0
Relays
Relay status
(see Table 5-10)
6976 12800-12801 2048 R 0 3
Event/time counters
Counter #1 7056
7057
13056-13057 2560 R/W 0 99999
Counter #2 7058
7059
13058-13059 2561 R/W 0 99999
Counter #3 7060
7061
13060-13061 2562 R/W 0 99999
Counter #4 7062
7063
13062-13063 2563 R/W 0 99999
Real-time values per phase (power values - P)
Voltage L1/L12
g
7136 LIN3 13312-13313 3072 R V 0 Vmax
Voltage L2/L23
g
7137 LIN3 13314-13315 3073 R V 0 Vmax
Voltage L3/L31
g
7138 LIN3 13316-13317 3074 R V 0 Vmax
Current L1 7139 LIN3 13318-13319 3075 R A 0 Imax
Current L2 7140 LIN3 13320-13321 3076 R A 0 Imax
Current L3 7141 LIN3 13322-13323 3077 R A 0 Imax
kW L1 7142 LIN3 13324-13325 3078 R kW -Pmax Pmax
kW L2 7143 LIN3 13326-13327 3079 R kW -Pmax Pmax
kW L3 7144 LIN3 13328-13329 3080 R kW -Pmax Pmax
kvar L1 7145 LIN3 13330-13331 3081 R kvar -Pmax Pmax
kvar L2 7146 LIN3 13332-13333 3082 R kvar -Pmax Pmax
kvar L3 7147 LIN3 13334-13335 3083 R kvar -Pmax Pmax
kVA L1 7148 LIN3 13336-13337 3084 R kVA 0 Pmax
kVA L2 7149 LIN3 13338-13339 3085 R kVA 0 Pmax
kVA L3 7150 LIN3 13340-13341 3086 R kVA 0 Pmax
Power factor L1 7151 LIN3 13342-13343 3087 R 0.001 -1.000 1.000
Power factor L2 7152 LIN3 13344-13345 3088 R 0.001 -1.000 1.000
Power factor L3 7153 LIN3 13346-13347 3089 R 0.001 -1.000 1.000
Reserved 7154 13348-13349 3090 R 0 0
Reserved 7155 13350-13351 3091 R 0 0
Reserved 7156 13352-13353 3092 R 0 0
Reserved 7157 13354-13355 3093 R 0 0
Reserved 7158 13356-13357 3094 R 0 0
Reserved 7159 13358-13359 3095 R 0 0
Reserved 7160 13360-13361 3096 R 0 0
Reserved 7161 13362-13363 3097 R 0 0
Reserved 7162 13364-13365 3098 R 0 0
Reserved 7163 13366-13367 3099 R 0 0
Reserved 7164 13368-13369 3100 R 0 0
Reserved 7165 13370-13371 3101 R 0 0
Voltage L12 7166 LIN3 13372-13373 3102 R V 0 Vmax
Voltage L23 7167 LIN3 13374-13375 3103 R V 0 Vmax
Voltage L31 7168 LIN3 13376-13377 3104 R V 0 Vmax
Real-time total values (P)
Total kW 7256 LIN3 13696-13697 3840 R kW -Pmax Pmax
Total kvar 7257 LIN3 13698-13699 3841 R kvar -Pmax Pmax
Total kVA 7258 LIN3 13700-13701 3842 R kVA 0 Pmax

Satec PM130 Specifications

General

Frequency Measurement Range	45 to 65 Hz
Power Supply	85-265V AC/DC, 100-300V DC
Display	LCD
Communication	RS485
Digital Inputs	2
Digital Outputs	2
Protocols	Modbus RTU
Accuracy	0.2% of reading
Power Accuracy	0.5%
