Satel OPAL Pro - Ball Bracket Mounting

SATEL OPAL Pro 9
Ball bracket mounting
1. Attach extra tamper switch:
– screw the holder to the tamper switch (Fig. 8-I),
– put the unit making the surface bigger on the tamper switch (Fig. 8-II),
– screw the tamper unit to the ball bracket (Fig. 8-IV).
2. Run the cable through the opening in the handle of the bracket.
3. Using wall plugs (screw anchors) and screws, fasten the ball bracket to the wall (Fig. 8-V).
4. Run the cable through the opening in the enclosure base (Fig. 8-VI).
5. Using screws, fasten the enclosure base to the ball bracket (Fig. 8-VII).
