12 OPAL Pro SATEL
Configuring by means of the detector buttons
By pressing buttons - (value decreasing) and + (value increasing) set the sensitivity /
detection threshold of the sensor.
Pressing buttons - and + simultaneously restores default settings for the configured
sensor. Keeping the buttons pressed for 3 seconds restores default settings for all
sensors.
Press the MODE button briefly in order to proceed and configure another sensor. Blinking of
the proper LED will indicate which sensor is being configured (see: “Signaling in the
configuration mode”).
Configuring by means of OPT-1 keyfob
The OPT-1 keyfob is available in SATEL’s product range.
Point the keyfob towards the detector and by pressing buttons (value decreasing) and
(value increasing) set the sensitivity / detection threshold of the sensor.
Pressing the button restores default settings for the configured sensor.
By pressing (the next sensor) or (the previous sensor) go to another sensor
configuration. Blinking of the proper LED will indicate which sensor is being configured
(see: “Signaling in the configuration mode”).
Ending configuration mode
Press the detector MODE button for 2 seconds or remove the common ground from the
SVCE terminal.
If the configuration mode was activated by means of the MODE button, it is
automatically exited after 20 minutes since the last operation performed by the user.
6. Anti-mask delay
To program the 60-second delay:
1. Power off the detector.
2. Place a jumper across the LED enable / disable pins.
3. Press and hold down the - detector button.
4. Power on the detector.
5. 3 seconds after power-on release the - button. The new settings will be saved.
To program the 1-second delay:
1. Power off the detector.
2. Remove the jumper from the LED enable / disable pins.
3. Press and hold down the - detector button.
4. Power on the detector.
5. 3 seconds after power-on release the - button. The new settings will be saved.
