SATEL OPAL Pro 5
terminals:
AM - anti-mask output (NC relay).
TMP - tamper output (NC).
NC - alarm output (NC relay).
COM - common ground.
+12V - power input.
LED - remote LED control.
SVCE - remote control of configuration mode.
D/N - dusk sensor output (OC type output).
pins to enable / disable the LED indicators.
microwave sensor.
green LED.
red LED.
yellow LED.
infrared receiver allowing to configure the detector by means of OPT-1 keyfob.
The keyfob is offered by SATEL.
anti-mask circuit LEDs.
buttons used during sensors sensitivity setting.
MODE button used for the detector configuration (see: “Configuring the detector”).
PIR sensor (dual element pyrosensor).
tamper switch activated by cover removal.
fixing screw holes.
dusk sensor.
On the other side of the electronics module there is a tamper switch activated by removing
the detector from the wall.
When mounting the detector on the angle or ball bracket, it is necessary to install
additional tamper switch.
4. Installation
Disconnect power before making any electrical connections.
If the detector is to be pet immune, it should be mounted at 2.4 m height with no
vertical tilt. It is especially important when mounting on a ball bracket.
