Page 8-15

Section 8. Troubleshooting

SATO CL408e/CL412e Service Manual

PN 9001078

Rev. A

8.9 Head Pattern Examples

FEED

DIRECTION

FACTORY DEFAULT

GOOD ADJUSTMENT

CLEAR, DARK,

EVEN TEXT

IRREGULAR UNEVEN

TEXT

POOR HEAD

ALIGNMENT, BALANCE

OUT OF ADJUSTMENT

POOR HEAD

ALIGNMENT, BALANCE

OUT OF ADJUSTMENT

ILLUSTRATIONS SHOWN ARE EXAMPLES

ONLY AND WILL NOT EXACTLY MATCH

YOUR OUTPUT
