SATO CL412e Service Manual

PN 9001078
Rev. A
Index-1
Index
SATO CL408e/CL412e Service Manual
Index
A
AC Fuse 1-3
AC Power Input Connector 1-3
Access Plate 1-5, 9-9
Accessories 1-9
Accessory (EXT) Connector 3-11
Alignment Pins 6-16
All Clear Mode 2-36
Auto Online Feed 2-28
Auto Online 2-13
B
Back-Feed Selection 2-5
Bar Codes 1-14
Base Cover Assembly 10-13
Baud Rate Selection 2-2
Bi-Directional Communications 3-10
C
Cable Requirements RS232 Serial Interface 3-7
Calendar 2-15, 9-30
Cancel Print Job 2-12
Card ->MemoryCopy 2-18
Card Format 2-24
Centronics Parallel Interface 3-2
Character Fonts 1-13
Character Pitch 2-16
CL408e/CL412e Differences 1-1
Clear Cutter Counter 7-5
Clear Dispenser Counter 7-4
Clear EEPROM 7-6
Clear Head Counters 7-3
Configuration 2-1
Connector, Optional 1-7,1-8
Counters HD DSP CUT LIFE 2-32
Cover Open Sensor 1-4, 2-16
Cover Plate 1-3
Cutter Assembly Option 10-23
D
Data Streams 3-4, 3-9
DC Power Voltage Checks 4-3
Default Setting Mode 2-34
Default Settings, Software 2-7
Default Settings 2-7
Digital Multimeter 4-5
Dimensions 1-2
Dip Switch Selections 2-7
Dip Switch Settings 2-1
Dip Switches 2-1
Dispenser Assembly Option 10-25
Display Panel PCB 6-28
Door Open Lever 1-4
Download User Defined Protocol Codes 2-37
Drive Roller 9-14
E
EEPROM Chip 9-28
Electrical Checks and Adjustments 4-1
Electrical Specifications IEEE1284 Parallel Interface 3-4
Electrical Specifications RS232C Serial Interface 3-6
Environment & Approvals 1-10
Error Signals 3-13, 8-10
Ethernet Interface 3-2, 3-10
Euro Code 2-30
Exit Advanced Mode 2-17
Ext Port 2-29
EXT Connector 1-3
EXT Print Start Signal Selection 2-5
External Signal Interface 2-5
External Signal Type Selection 2-6
Eye-Mark Adjustment 4-11
F
Factory Reset Procedure 9-29
Factory Resets 7-1
Factory Settings/Test Print 7-2
Feed Key 1-7, 1-8
Feed on Error 2-28
Firmware Download 2-4
Flash Memory Expansion Installation 9-23
Flash Memory Module 6- 5, 6-6, 9-25
Flash Memory 9-24
Forward/Backfeed 2-29
Frame Assembly 10-2
Front Access Door 1- 2,1-4
Fuses 6-7
G
General Printer Specifications 1-10
General Specifications RS232C Serial Interface 3-6
General Specifications USB Interface 3-10
H
Head Check Selection 2-3
Head Latch Lever 6-15, 6-16
Head Open Lever 1-4
Head Open Switch 6-27
Head Pattern Examples 8-15
Hex Dump Diagnostic Labels 8-17
Hex Dump Mode 2-38
Hex Dump Selection 2-3
Horizontal Offset 2-14

SATO CL412e Specifications

General

Print Resolution	203 dpi
Print Width	4.1 inches
Print Method	Thermal Transfer / Direct Thermal
Operating Temperature	41°F to 104°F (5°C to 40°C)
Media Thickness	0.0025" to 0.0100"
Power Supply	AC 100V to 240V, 50/60 Hz
Humidity	30 - 80% RH non-condensing
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
