SATO CL412e Service Manual

Page 5-1
SATO CL408e/CL412e Service Manual
PN 9001078
Rev. A
#
Section
Mechanical Adjustments
5.1 Overview
The SATO CL408e/CL412e contain adjustable sub-assemblies. This means that during
your regular maintenance, your service technicians are able to make adjustments to reset
the printer to factory specifications therby ensuring optimum performance of your printer
The main mechnaical sub-assemblies are:
• Ribbon Unwind/Rewind Assembly's
• Ribbon Guide Roller Assembly
• Print Head Assembly
• Drive Belt Assembly
In this section you will find procedures for:
• Ribbon Clutch Adjustments
• Ribbon Guide Plate Adjustment
• Tear Plate Adjustment
• Print Head Position Alignment
• Print Head Balance Adjustment
• Print Head Alignment Adjustment
• Timing Belt Tension Adjustment
Checks and adjustments in this section require standard metric tools.
Other equipment is listed where needed.

SATO CL412e Specifications

General

Print Resolution	203 dpi
Print Width	4.1 inches
Print Method	Thermal Transfer / Direct Thermal
Operating Temperature	41°F to 104°F (5°C to 40°C)
Media Thickness	0.0025" to 0.0100"
Power Supply	AC 100V to 240V, 50/60 Hz
Humidity	30 - 80% RH non-condensing
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
