Section 3. Configuration
SATO M-84PRO PN 9001105 Rev. A Page 3-3
Sensor Type Selection (DSW2-2). Selects between the use of a label gap or a reflective Eye-
Mark detector.
Head Check Selection (DSW2-3). When selected, the printer will check for head elements
that are electrically malfunctioning.
Hex Dump Selection (DSW2-4). Selects Hex Dump mode (see page 3-21).
Receive Buffer Selection(DSW2-5). Selects the operating mode of the receive buffer. See
Section 6.Interface Specifications for more information.
If a 10/100BaseT LAN card is installed, DS2-5 has the following definitions:
DSW2-2 SETTING
Off Gap
On Eye-Mark
DSW2
ON
OFF
12345678
DSW2-3 SETTING
Off Disabled
On Enabled
DSW2
ON
OFF
12345678
DSW2-4 SETTING
Off Disabled
On Enabled
DSW2
ON
OFF
12345678
DSW2-5 SETTING
Off Single Job
On Multi Job
DSW2
ON
OFF
12345678
DSW2-5 SETTING
Off ENQ Response
On Periodic Response
