Section 3. Configuration
SATO M-84PRO PN 9001105 Rev. A Page 3-5
Label Sensor Selection (DSW3-3). Enables or disables the Label Sensor. If the Sensor is
enabled, it will detect the edge of the label and position it automatically. If it is disabled, the
positioning must be under software control using Line Feed commands.
Back-Feed Selection (DSW3-4). When Back-Feed is enabled, the printer will position the
last printed label for dispensing and retract it before printing the next label. The amount of
backfeed offset is adjustable.
External Signal Interface. See Section 6: Interface Specifications for information on the
External Signals.
EXT Print Start Signal Selection (DSW3-5). Allows an external device to initiate a label
print for synchronization with the applicator. When DSW3-5 is On, the unit is in the
Continuous print mode, Backfeed is disabled and External Signals are ignored.
DSW3-3 SETTING
Off Not Used
On Sensor Used
DSW3
ON
OFF
12345678
DSW3-4 SETTING
Off Disabled
On Enabled
DSW3
ON
OFF
12345678
DSW3-5 SETTING
Off Enabled
On Disabled
DSW3
ON
OFF
12345678
