Section 3. Configuration
Page 3-6 PN 9001105 Rev. A SATO M-84PRO
External Signal Type Selection (DSW3-6, DSW3-7). Both the polarity and signal type (level
or pulse) of the external print synchronizing signal can be selected.
Repeat Print via External Signal (DSW3-8). Allows the applicator to reprint the current
label in the print buffer.
DSW3-6 DSW3-7 SETTING
Off Off Type 4
Off On Type 3
On Off Type 2
On On Type 1
DSW1
ON
OFF
12345678
DSW3-8 SETTING
Off Enabled
On Disabled
DSW3
ON
OFF
12345678
