Unit 2: Technical Data
S8400 Series Operator Manual
2-4 PN: 9001160 (C)
RIBBON
SENSING
CHARACTER FONT CAPABILITIES
Media Handling
Media Width (mm) Label Supply Load (grams) Liner Rewind Load (grams)
13 to 18 < 250 < 150
18 to 28 < 400 < 300
28 to 48 < 900 < 300
48 to 63 < 1,200 < 400
63 to 83 < 1,200 < 650
83 + < 1,400 < 800
RIBBON
Width
Minimum: 0.98 Inches (25mm)
Maximum: 5.04 Inches (128mm)
Length 3280 Feet (1000m)
Ribbon Handling
Ribbon Length (m) Ribbon Width (mm) Label Pitch (mm)
1,000 76 60 +
600 39.5 to 75 25 +
450 < 39.5 < 25
Wound Face In / Face Out
Roll Diameter 4.252 Inches (108mm)
Core Diameter 1.01 +/-0.008 Inches (25.6mm +/-0.2mm)
Color Black (standard), Other Tints (non-standard)
SENSING
Gap Adjustable
Reflective I-Mark Adjustable
Ribbon Near End Enable/Disable
Media Out Adjustable
Cover-Open Constant
Head-Open Constant
CHARACTER FONT CAPABILITIES
MATRIX FONTS
XU 5 dots W x 9 dots H (Helvetica)
XS 17 dots W x 17 dots H (Univers Condensed Bold)
XM 24 dots W x 24 dots H (Univers Condensed Bold)
OA Font (OCR-A)
203dpi (8dots/mm): 15 dots W x 22 dots H
305dpi (12dots/mm): 22 dots W x 33 dots H
609dpi (24dots/mm): 44 dots W x 66 dots H
MEDIA
