Location Description Length = x Width = y Height = z Point to Point
2 Center Line — — — x
a Rear Cradle Attachment Hole 2100 332 201 x
b
Front Rail Outer Torque Box
Master Gage Hole
2218 600 121 x
c
Floor Pan Drain Hole
Front Hole
2420 542 190 x
d
Front Rail Hole Front of Rear
Portion
2675 421 134 x
e
Floor Pan Sled Rail
Front Hole
2585 162 133 x
f
Front Rail Hole Rear of Rear
Portion
3171 601 167 x
g
Floor Pan Sled Rail
Rear Hole
3374 170 144 x
h Floor Pan Rear Drain Hole 3378 521 190 x
i
Rear Rail Torque Box Master
Gage Hole
3593 592 203 x
j Front Rail Hole 3826 600 184 x
k 5 Bar Outer Hole 4235 180 354 x
l Rear Rail Rear Slot 4757 487 372 x
m
Rear Compartment Floor
Pan Drain Hole
5000 40 221 x
t
Front Cradle
Attachment Hole
1371 474 231 x
ntoo
Rear Rail Rear Hole to Rear
Rail Master Gage Hole
— — — 1174
otop
Rear Rail Master Gage Hole
to Front Rail Rear Hole
— — — 419
ptoq
Front Rail Rear Hole to Front
Rail Master Gage Hole
— — — 956
qtos
Front Rail Master Gage Hole
to Front Cradle
Attachment Hole
— — — 847
rtos
Rear Cradle Attachment Hole
to Front Cradle
Attachment Hole
— — — 742
stot
Front Cradle Attachment
Hole to Front Cradle
Attachment Hole
— — — 948
ttor
Front Cradle Attachment
Hole to Opposite Rear
Cradle Attachment
— — — 1087
rtof
Rear Cradle Attachment Hole
to Opposite Rear Rail
Rear Hole
— — — 1756
rtoi
Rear Cradle Attachment Hole
to Rear Rail Master
Gage Hole
— — — 1756
ftoo
Front Rail Rear Hole to
Opposite Rear Rail Master
Gage Hole
— — — 1243
otol
Rear Rail Master Gage Hole
to Opposite Rear Rail
Rear Hole
— — — 1591
lton
Rear Rail Rear Hole to Rear
Rail Rear Hole
— — — 974
All dimensions are measured from a zero line, a center line, and a common datum. All dimensions are symmetrical unless
otherwise specified.
2003 Saturn Ion 3-11
