7. Within the recommended sectioning areas, mark
the location of the sectioning cut lines on the
vehicle.
Important: Note the number and location of the
factory welds for installation of the quart panel.
8. Locate and drill out all factory welds.
Important: Do NOT damage any other panels or
reinforcements when cutting at the marked locations.
9. Cut the panel at the location laid out in the
previous steps.
10. Remove the damaged quarter panel.
875635
884763
875636
3-134 2003 Saturn Ion
