Saturn 2003 Ion User Manual

Location Description Length = x Width = y Height = z Point to Point
a
Rear Upper Hinge
Upper Hole
3301 746 776 x
b
Quarter Panel Dog Leg
Outer Attachment Hole
4226 779 768 x
c
Fascia Bracket Rear
Upper Hole
4974 746 596 x
d
Quarter Panel Dog Leg
Outer Attach Hole
4068 767 617 x
e
Quarter Panel Dog Leg
Outer Attachment Hole
3991 767 437 x
f
Quarter Panel Dog Leg
Outer Attachment Hole
3780 762 250 x
g Rear Lower Hinge Rear Hole 3289 746 430 x
h Rear Lower Hinge Front Hole 3254 747 430 x
i Front Lower Hinge Rear Hole 2259 748 396 x
j Rear Cradle Attachment Hole 2100 332 201 x
k
Front Lower Hinge
Front Hole
2225 740 396 x
l Front Rail Outer Panel Hole 1840 463 430 x
m
Front Cradle
Attachment Hole
1371 500 280 x
n
Weld Nut Hole Washer Bottle
Attachment
1222 540 409 x
o
Front Upper Outer Rail
Front Hole
1880 743 760 x
p Body Side Control Hole 2175 745 640 x
q
Front Upper Hinge
Front Hole
2224 737 754 x
r Front Upper Hinge Rear Hole 2260 737 754 x
s
Front Door Latch Striker
Upper Hole
3263 748 574 x
t
Rear Upper Hinge
Lower Hole
3299 754 741 x
u
Rear Latch Striker
Upper Hole
4145 739 736 x
v
Rear Door Opening Point to
Point Measurements to Weld
Flange Die Marks
— — — 1015
w
Rear Door Opening Point to
Point Measurement to Weld
Flange Die Marks
— — — 1188
x
Front Door Opening Point to
Point Measurement to Weld
Flange Die Marks
— — — 970
y
Front Door Opening Point to
Point Measurement to Weld
Flange Die Marks
— — — 1337
All dimensions are measured from a zero line, a center line, and a common datum. All dimensions are symmetrical unless
otherwise specified.
3-14 2003 Saturn Ion
