Important: Note the number and location of the
factory welds for installation of the front wheelhouse
extension.
6. Locate and drill out all the necessary
factory welds.
7. Remove the front wheelhouse extension.
Installation Procedure
Important: If the location of the original plug weld
holes can not be determined, space the plug
weld holes every 40 mm (1 1/2 in) apart.
1. Drill 8 mm (5/16 in) plug weld holes in the service
part as necessary in the locations noted from the
original panel.
2. Prepare all mating surfaces as necessary.
3. Apply 3M Weld-Thru Coating P/N 05916 or
equivalent to all mating surfaces.
868717
868718
865281
2003 Saturn Ion 3-35
