9. Remove the damaged roof panel.
Installation Procedure
1. Prepare all mating surfaces as necessary.
2. Apply 3M Weld-Thru Coating P/N 05916 or
equivalent to all mating surfaces.
Important: Place the urethane adhesive on the
outboard side of the roof panel stud hole locations.
3. Place a 10 mm (3/8 in) diameter bead of urethane
adhesive GM P/N 12346392 on the perimeter of
the vehicle roof attachment points.
870883
870876
874273
2003 Saturn Ion
3-83
2003 Saturn Ion
