Appendix B: EDID Optimization
Enhanced HDMI source capabilities can create compatibility issue with less capable displays. Below are tables to show examples of possible EDID changes for
testing and use.
Default EDID (4K@60hz 4:2:0 8 bit video, PCM audio up to 8 channel)
HDCP 1.4
Source
HDCP 2.2
4K@60Hz
4:4:4 HDR
capable TV
HDCP 2.2
4K@60hz
4:4:4
non-HDR
capable TV
HDCP 2.2
4K@60hz
4:2:0
non-HDR
capable TV
HDCP 1.4
1080p TV
HDCP 2.2
4K@60hz
4:4:4 HDR
AVR HBR
audio
capable
HDCP 2.2
4K@60hz
4:2:0 non-
HDR AVR
HBR audio
capable
HDCP 1.4
1080p
AVR Up to
Dolby audio
capable
Analog
audio output
on the VIM
chassis in
use
VOM Video
Mode
N/A Pass-Though
(Use Input)
Pass-Though
(Use Input)
Pass-Though
(Use Input)
Resolution
Scaled to
1080p
Pass-Though
(Use Input)
Pass-Though
(Use Input)
Resolution
Scaled to
1080p
N/A
VOM Audio
Mode
N/A Multi to 2
Channel
checked
Multi to 2
Channel
checked
Multi to 2
Channel
checked
Multi to 2
Channel
checked
Native
HDMI audio
(Multichannel
PCM)
Native
HDMI audio
(Multichannel
PCM)
All HDMI
audio
Source audio
input 2
channel
PCM only
EDID: 4K@60hz 4:2:0 8 bit video, PCM audio up to 8 channel, Dolby/DTS surround audio
HDCP 1.4
Source
HDCP 2.2
4K@60Hz
4:4:4 HDR
capable TV
HDCP 2.2
4K@60hz
4:4:4
non-HDR
capable TV
HDCP 2.2
4K@60hz
4:2:0
non-HDR
capable TV
HDCP 1.4
1080p TV
HDCP 2.2
4K@60hz
4:4:4 HDR
AVR HBR
audio
capable
HDCP 2.2
4K@60hz
4:2:0 non-
HDR AVR
HBR audio
capable
HDCP 1.4
1080p
AVR Up to
Dolby audio
capable
Analog
audio output
on the VIM
chassis in
use
VOM Video
Mode
N/A Pass-Though
(Use Input)
Pass-Though
(Use Input)
Pass-Though
(Use Input)
Resolution
Scaled to
1080p
Pass-Though
(Use Input)
Pass-Though
(Use Input)
Resolution
Scaled to
1080p
N/A
VOM Audio
Mode
N/A Multi to 2
Channel
checked (If
Dolby/ DTS
are used they
will be passed
to the HDMI
output)
Multi to 2
Channel
checked (If
Dolby/ DTS
are used they
will be passed
to the HDMI
output)
Multi to 2
Channel
checked (If
Dolby/ DTS
are used they
will be passed
to the HDMI
output)
Multi to 2
Channel
checked (If
Dolby/ DTS
are used they
will be passed
to the HDMI
output)
Native HDMI
audio
Native HDMI
audio
Native HDMI
audio
Source
audio input
2 channel
PCM only
(If encoded
audio is
used by the
source analog
outputs will
output audio
noise)
