Savant IP Video Deployment Guide | 009-1977-00 45 Perseverance Way, Hyannis, MA 02601
Copyright 2020 Savant Systems, Inc | 200924 26 of 28 Savant.com | 508.683.2500
EDID: 4K@60hz 4:2:0 8 bit video, PCM audio up to 8 channel, Dolby/DTS surround audio, Dolby Digital Plus
HDCP 1.4
Source
HDCP 2.2
4K@60Hz
4:4:4 HDR
capable TV
HDCP 2.2
4K@60hz
4:4:4
non-HDR
capable TV
HDCP 2.2
4K@60hz
4:2:0
non-HDR
capable TV
HDCP 1.4
1080p TV
HDCP 2.2
4K@60hz
4:4:4 HDR
AVR HBR
audio
capable
HDCP 2.2
4K@60hz
4:2:0 non-
HDR AVR
HBR audio
capable
HDCP 1.4
1080p
AVR Up to
Dolby audio
capable
Analog
audio output
on the VIM
chassis in
use
VOM Video
Mode
N/A Pass-Though
(Use Input)
Pass-Though
(Use Input)
Pass-Though
(Use Input)
Resolution
Scaled to
1080p
Pass-Though
(Use Input)
Pass-Though
(Use Input)
Resolution
Scaled to
1080p
N/A
VOM Audio
Mode
N/A Multi to 2
Channel
checked (If
Dolby/DTS
are used
they will be
passed to the
HDMI output)
(Many TVs do
not decode
Dolby Digital
Plus)
Multi to 2
Channel
checked (If
Dolby/DTS
are used
they will be
passed to the
HDMI output)
(Many TVs do
not decode
Dolby Digital
Plus)
Multi to 2
Channel
checked (If
Dolby/DTS
are used
they will be
passed to the
HDMI output)
(Many TVs do
not decode
Dolby Digital
Plus)
Multi to 2
Channel
checked (If
Dolby/DTS
are used
they will be
passed to the
HDMI output)
(Many TVs do
not decode
Dolby Digital
Plus)
Native HDMI
audio
Native HDMI
audio
Native HDMI
audio
Source
audio input
2 channel
PCM only
(If encoded
audio is
used by the
source analog
outputs will
output audio
noise)
EDID: 4K@60hz 4:2:0 8 bit video, PCM audio up to 8 channel, Dolby/DTS surround audio, HBR audio (Dolby TureHD/DTS HD)
HDCP 1.4
Source
HDCP 2.2
4K@60Hz
4:4:4 HDR
capable TV
HDCP 2.2
4K@60hz
4:4:4
non-HDR
capable TV
HDCP 2.2
4K@60hz
4:2:0
non-HDR
capable TV
HDCP 1.4
1080p TV
HDCP 2.2
4K@60hz
4:4:4 HDR
AVR HBR
audio
capable
HDCP 2.2
4K@60hz
4:2:0 non-
HDR AVR
HBR audio
capable
HDCP 1.4
1080p
AVR Up to
Dolby audio
capable
Analog
audio output
on the VIM
chassis in
use
VOM Video
Mode
N/A Pass-Though
(Use Input)
Pass-Though
(Use Input)
Pass-Though
(Use Input)
Resolution
Scaled to
1080p
Pass-Though
(Use Input)
Pass-Though
(Use Input)
Resolution
Scaled to
1080p
N/A
VOM Audio
Mode
N/A Multi to 2
Channel
checked (If
Dolby/DTS
are used
they will be
passed to the
HDMI output)
(TVs are not
HBR audio
capable)
Multi to 2
Channel
checked (If
Dolby/DTS
are used
they will be
passed to the
HDMI output)
(TVs are not
HBR audio
capable)
Multi to 2
Channel
checked (If
Dolby/DTS
are used
they will be
passed to the
HDMI output)
(TVs are not
HBR audio
capable)
Multi to 2
Channel
checked (If
Dolby/DTS
are used
they will be
passed to the
HDMI output)
(TVs are not
HBR audio
capable)
Native HDMI
audio
Native HDMI
audio
Native HDMI
audio
Source
audio input
2 channel
PCM only
(If encoded
audio is
used by the
source analog
outputs will
output audio
noise)
