Savant PAV-VIMAP8S User Manual

Savant IP Video with Audio Processing Deployment Guide
Copyright © 2018 Savant System, LLC
009-1621-01 | 181107
31 of 32
EDID: 4K@60hz 4:4:4 8 bit video, PCM audio up to 8 channel)
HDCP 1.4
Source
HDCP 2.2
4K@60hz
4:4:4 HDR
capable TV
HDCP 2.2
4K@60hz
4:4:4 non-
HDR capable
TV
HDCP 2.2
4K@60hz
4:2:0 non-
HDR capable
TV
HDCP 1.4
1080p TV
HDCP 2.2
4K@60hz
4:4:4 HDR
AVR
HBR audio
capable
HDCP 2.2
4K@60hz
4:2:0 non-
HDR AVR
HBR audio
capable
HDCP 1.4
1080p AVR
Up to Dolby
audio
capable
Analog audio
output on the
VIM chassis in
use
VOM Video
Mode
N/A
Pass-Though
(Use Input)
Pass-Though
(Use Input)
Pass-Though
(Use Input)
(4:4:4
content will
need to be
scaled)
Resolution
Scaled to
1080p
(If source
uses HDCP
2.2 video will
NOT display)
Pass-Though
(Use Input)
Pass-Though
(Use Input)
(4:4:4
content will
need to be
scaled)
Resolution
Scaled to
1080p
(If source
uses HDCP
2.2 video will
NOT display)
N/A
VOM Audio
Mode
N/A
Multi to 2
Channel
checked
Multi to 2
Channel
checked
Multi to 2
Channel
checked
Multi to 2
Channel
checked
Native HDMI
audio
(Multi-
channel
PCM)
Native HDMI
audio
(Multi-
channel
PCM)
All HDMI
audio
Source audio
input 2 channel
PCM only
EDID: 4K@60hz 4:4:4 8 bit video, HDR and Deep Color enabled, PCM audio up to 8 channel)
HDCP 1.4
Source
HDCP 2.2
4K@60hz
4:4:4 HDR
capable TV
HDCP 2.2
4K@60hz
4:4:4 non-
HDR capable
TV
HDCP 2.2
4K@60hz
4:2:0 non-
HDR capable
TV
HDCP 1.4
1080p TV
HDCP 2.2
4K@60hz
4:4:4 HDR
AVR
HBR audio
capable
HDCP 2.2
4K@60hz
4:2:0 non-
HDR AVR
HBR audio
capable
HDCP 1.4
1080p AVR
Up to Dolby
audio
capable
Analog audio
output on the
VIM chassis in
use
VOM Video
Mode
N/A
Pass-Though
(Use Input)
Pass-Though
(Use Input)
(Video will
display but
will not be in
HDR)
Pass-Though
(Use Input)
(Video will
display but
will not be in
HDR)
(4:4:4
content will
need to be
scaled)
Resolution
Scaled to
1080p
(If source
uses HDCP
2.2 video will
NOT display)
Pass-Though
(Use Input)
Pass-Though
(Use Input)
(Video will
display but
will not be in
HDR)
(4:4:4
content will
need to be
scaled)
Resolution
Scaled to
1080p
(If source
uses HDCP
2.2 video will
NOT display)
N/A
VOM Audio
Mode
N/A
Multi to 2
Channel
checked
Multi to 2
Channel
checked
Multi to 2
Channel
checked
Multi to 2
Channel
checked
Native HDMI
audio
(Multi-
channel
PCM)
Native HDMI
audio
(Multi-
channel
PCM)
All HDMI
audio
Source audio
input 2 channel
PCM only
