42 © Scania CV 2009
Air cleaner
8. Daily:
Test reading of vacuum indicator
If the red indicator bar is entirely visible, change or clean the air cleaner filter
element, point 10. This is particularly important if the engine is run at high
loads and high speed.
9. Every 200 hours:
Cleaning the air cleaner’s coarse
cleaner
1. Remove the cover from the coarse cleaner (2).
2. Remove the conical coarse separator. Empty out the particles of dirt and
clean it.
3. Fit the coarse cleaner as shown in the figure and screw the cover into
place.
10. Every 1,200 hours:
Cleaning or changing filter element
Note: Clean or renew the filter element earlier if the vacuum indicator
shows red.
Dismantling
1. Remove the cover from the air cleaner.
2. Renew or clean the filter element.
Note: There is always a risk that the filter element will be damaged
during cleaning. The filter element can only be cleaned a
maximum of four times. After cleaning, it has poorer dust
capacity than a new filter element.
3. Mark the filter when it has been cleaned.
Cleaning the filter element
- Carefully blow the filter element clean using dry compressed air from
the inside.
Note: This filter element must not be washed with water.
1. Cover
2. Filter element
3. Filter house
Only use genuine Scania air
filters.
Renew the filter element if it is
damaged.
Danger of engine damage if the
filter element is damaged.
Never start the engine without
the air filter.
There is a risk of injury or
engine damage.
1
2
3
The coarse cleaner must always
be fitted in an upright position.
1. Filter element
2. Coarse cleaner
3. Cover
4. Vacuum indicator
43
21
Important
!
Important
!
WARNING
!
