82 Appendices
C TECHNICAL SPECIFICATIONS
Physical Characteristics
Weight (V-1020) Approx. 240 gr. (incl. cable)
Weight (V-1020BT) Approx. 195 gr. (incl. batteries)
Material ABS Plastic
Connector RJ 45C 10Pins
Dimension 186.8 mm x 81.6 mm x 63.9 mm
Physical Characteristics Bluetooth Cradle
Weight Approx 150 gr.
Material ABS Plastic
Connector RJ 45C 10Pins
Dimension 129.9 mm x 120 mm x 71.4 mm
Operational
Light source Visible Red light 650nm + 10nm
Scan rate 200scans/sec auto adaptive in linear mode.
56 images/sec auto adaptive in 2D mode.
Optical resolution 752 Horizontal x 480 Vertical pixels, 256 gray levels.
Scan angle 38° Horizontal, 25° Vertical
Interface RS-232 and USB
Indicators (led) Green = good read
Electrical Characteristics (V-1020 wired model)
Operation Voltage 5 VDC ±5%
Current Operating 450 mA (max) @ 5 VDC
Current Standby 37 mA typical @ 5 VDC
AC transformers 5.2 VDC @ 650 mA / Input AC 100-240V
