P746/EN ST/G31 Settings
(ST) 4-
22
MiCOM P746
ST
Setting Range
Menu Text Default Setting
Min. Max.
Step Size
RP2 Address 255 0 255 1
This cell sets the unique address for the relay such that only one relay is accessed by
master station software.
RP2 Inactivity Timer 15 mins. 1 mins. 30 mins. 1 min.
This cell controls how long the relay will wait without receiving any messages on the rear
port before it reverts to its default state, including resetting any password access that was
enabled.
RP2 Baud Rate 19200 bits/s 9600 bits/s, 19200 bits/s or 38400 bits/s
This cell controls the communication speed between relay and master station. It is
important that both relay and master station are set at the same speed setting.
1.3.6.1.3 Ethernet port
Setting Range
Menu Text Default Setting
Min. Max.
Step Size
NIC Protocol
IEC 61850
Indicates that IEC 61850 will be used on the rear Ethernet port.
NIC MAC Address
Ethernet MAC Address
Indicates the MAC address of the rear Ethernet port.
NIC Tunl Timeout 5 mins
1 min 30 mins 1 min
Duration of time waited before an inactive tunnel to MiCOM S1 is reset.
NIC Link Report Alarm
Alarm, Event, None
Configures how a failed/unfitted network link (copper or fiber) is reported:
Alarm - an alarm is raised for a failed link
Event - an event is logged for a failed link
None - nothing reported for a failed link
NIC Link Timeout 60s 0.1s 60s 0.1s
Duration of time waited, after failed network link is detected, before communication by the
alternative media interface is attempted.
