Settings P746/EN ST/G31
MiCOM P746 (ST) 4-
5
ST
Menu Text Default Setting Available Settings
Commission Tests Visible Invisible or Visible
Sets the Commissioning Tests menu visible further on in the relay settings menu.
Setting Values Primary Primary or Secondary
This affects all protection settings that are dependent upon CT and VT ratios.
Control Inputs Visible Invisible or Visible
Activates the Control Input status and operation menu further on in the relay setting menu.
Ctrl I/P Config. Visible Invisible or Visible
Sets the Control Input Configuration menu visible further on in the relay setting menu.
Ctrl I/P Labels Visible Invisible or Visible
Sets the Control Input Labels menu visible further on in the relay setting menu.
Direct Access Enabled
Enabled/Disabled/Hotkey
only/CB Cntrl. only
Defines what CB control direct access is allowed. Enabled implies control via menu,
hotkeys etc.
Function Key Visible Invisible or Visible
Sets the Function Key menu visible further on in the relay setting menu.
RP1 Read Only Disabled Enabled or Disabled
Enable Remote Read Only Mode on RP1 courier or IEC60870-5-103 communication
protocol.
RP2 Read Only Disabled Enabled or Disabled
Enable Remote Read Only Mode on RP2 courier communication protocol.
NIC Read Only Disabled Enabled or Disabled
Enable Remote Read Only Mode on the Network Interface card (IEC 61850 tunneled
courier).
LCD Contrast 11 0…31
Sets the LCD contrast.
1.1.1 Default settings restore
To restore the default values to the settings in any protection settings group, set the ‘restore
defaults’ cell to the relevant group number. Alternatively it is possible to set the ‘restore
defaults’ cell to ‘all settings’ to restore the default values to all of the relay’s settings, not just
the protection groups’ settings. The default settings will initially be placed in the scratchpad
and will only be used by the relay after they have been confirmed. Note that restoring
defaults to all settings includes the rear communication port settings, which may result in
communication via the rear port being disrupted if the new (default) settings do not match
those of the master station.
